Koło kompresji 821866-0001
Wymiary
- A Size A
- 49.00 mm
- A1 Size A1
- 50.80 mm
- B Size B
- 37.00 mm
- C Size C
- 4.30 mm
- C1 Size C1
- 4.00 mm
- D Size D
- 26.50 mm
- E Size E
- 4.08 mm
O produkcie
GA-03-0027 - Koło kompresji
Marka: TurboCentras
TurboCentras Reference: GA-03-0027
GA-03-0027 - Alternative numbers
TCP (TurboCentras part number): GA-03-0027
TCO (TurboCentras old part number): GT14-13B
GA-03-0027 - Compatibility table
| Compressor wheel GA-03-0027 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GTB1449VZ | 819891-0005 | 819891-0005 | -- |
| Garrett | GTD1449VZ | 821866-0001 | 821866-0001 | 04L253010H |
| Garrett | GTD1449V | 821866-0002 | 821866-0002, 821866-5002S | 04L253010HV260 |
| Garrett | GTD1449V | 821866-0003 | 821866-0003, 821866-5003S | 04L253010HV280 |
| Garrett | GTD1449V | 821866-0004 | 821866-0004, 821866-5004S | 04L253010HV310 |
| Garrett | GTD1449VZ | 823665-0007 | 823665-0007, 823665-5007S | 282314A610 |
| Garrett | GTD1449VKZ | 831120-0005 | 831120-0005 | -- |
| Garrett | GTD1449VZ | 831120-0006 | 831120-0006, 831120-5006S | A6540900800 |
| Garrett | GTD1449VK | 831120-0007 | 831120-0007, 831120-5007S | A6540902400 |
| Garrett | GTD1449VK | 831120-0008 | 831120-0008, 831120-5008S | A6540904500 |
| Garrett | GTD1449VKZ | 831120-0009 | 831120-0009 | A6540904500 |
| Garrett | GTD1449VK | 831120-0010 | 831120-0010, 831120-5010S | A6540904500 |
| Garrett | GTD1749V | 836825-0003 | 836825-0003, 836825-5003S | 5801922491 |
| Garrett | GTD17V | 836825-0009 | 836825-0009, 836825-5009S | 5801922491 |
| Garrett | GTD1749V | 839765-0001 | 839765-0001, 839765-5001S, 839765-9001S | 5801930226 |
GA-03-0027 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Deep Super
A (Size A): 49.00
A1 (Size A1): 50.80
B (Size B): 37.00
C (Size C): 4.30
C1 (Size C1): 4.00
D (Size D): 26.50
E (Size E): 4.08
GA-03-0027, GT14-13B
819891-0005, 04L253010H, 821866-0001, 04L253010HV260, 821866-0002, 821866-5002S, 04L253010HV280, 821866-0003, 821866-5003S, 04L253010HV310, 821866-0004, 821866-5004S, 282314A610, 823665-0007, 823665-5007S, 831120-0005, 831120-0006, 831120-5006S, A6540900800, 831120-0007, 831120-5007S, A6540902400, 831120-0008, 831120-5008S, A6540904500, 831120-0009, A6540904500, 831120-0010, 831120-5010S, A6540904500, 5801922491, 836825-0003, 836825-5003S, 5801922491, 836825-0009, 836825-5009S, 5801930226, 839765-0001, 839765-5001S, 839765-9001S
Data updated: 2023-02-16 12:09:11
Specyfikacja
Producent
SKU
GA-03-0027
Stan
Nowy
Główny numer
GT14-13B, GA-03-0027, CW-1136B
Numer OEM
831120-0009, 821866-0001, 821866-0002, 821866-0003, 821866-0004, 819891-0005, 836825-0003, 831120-0006, 831120-0007, 831120-0008, 831120-0010, 836825-0009, 839765-0001, 823665-0007, 831120-0005
Gwarancja
12 miesięcy gwarancji producenta
