Compressor wheel 821866-0001

GA-03-0027 - Compressor wheel

Brand: TurboCentras

TurboCentras Reference: GA-03-0027

GA-03-0027 - Alternative numbers

TCP (TurboCentras part number): GA-03-0027

TCO (TurboCentras old part number): GT14-13B

GA-03-0027 - Compatibility table

Compressor wheel GA-03-0027 - Compatible turbochargers
TURBO MAKER	TURBO MODEL	TURBO REFERENCE	TURBO PART NUMBER	TURBO OE NUMBER
Garrett	GTB1449VZ	819891-0005	819891-0005	--
Garrett	GTD1449VZ	821866-0001	821866-0001	04L253010H
Garrett	GTD1449V	821866-0002	821866-0002, 821866-5002S	04L253010HV260
Garrett	GTD1449V	821866-0003	821866-0003, 821866-5003S	04L253010HV280
Garrett	GTD1449V	821866-0004	821866-0004, 821866-5004S	04L253010HV310
Garrett	GTD1449VZ	823665-0007	823665-0007, 823665-5007S	282314A610
Garrett	GTD1449VKZ	831120-0005	831120-0005	--
Garrett	GTD1449VZ	831120-0006	831120-0006, 831120-5006S	A6540900800
Garrett	GTD1449VK	831120-0007	831120-0007, 831120-5007S	A6540902400
Garrett	GTD1449VK	831120-0008	831120-0008, 831120-5008S	A6540904500
Garrett	GTD1449VKZ	831120-0009	831120-0009	A6540904500
Garrett	GTD1449VK	831120-0010	831120-0010, 831120-5010S	A6540904500
Garrett	GTD1749V	836825-0003	836825-0003, 836825-5003S	5801922491
Garrett	GTD17V	836825-0009	836825-0009, 836825-5009S	5801922491
Garrett	GTD1749V	839765-0001	839765-0001, 839765-5001S, 839765-9001S	5801930226

GA-03-0027 - Part Properties

Blades (Compressor wheel blades count): 6/6

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Billet

Back (Compressor wheel back design): Deep Super

A (Size A): 49.00

A1 (Size A1): 50.80

B (Size B): 37.00

C (Size C): 4.30

C1 (Size C1): 4.00

D (Size D): 26.50

E (Size E): 4.08

---

GA-03-0027, GT14-13B

---

819891-0005, 04L253010H, 821866-0001, 04L253010HV260, 821866-0002, 821866-5002S, 04L253010HV280, 821866-0003, 821866-5003S, 04L253010HV310, 821866-0004, 821866-5004S, 282314A610, 823665-0007, 823665-5007S, 831120-0005, 831120-0006, 831120-5006S, A6540900800, 831120-0007, 831120-5007S, A6540902400, 831120-0008, 831120-5008S, A6540904500, 831120-0009, A6540904500, 831120-0010, 831120-5010S, A6540904500, 5801922491, 836825-0003, 836825-5003S, 5801922491, 836825-0009, 836825-5009S, 5801930226, 839765-0001, 839765-5001S, 839765-9001S

---
