Koło kompresji 737689-0001
Wymiary
- A Size A
- 56.00 mm
- A1 Size A1
- 56.00 mm
- B Size B
- 43.40 mm
- C Size C
- 4.95 mm
- C1 Size C1
- 3.75 mm
- D Size D
- 31.00 mm
- E Size E
- 5.08 mm
O produkcie
GA-03-0072 - Koło kompresji
Marka: TurboCentras
TurboCentras Reference: GA-03-0072
GA-03-0072 - Alternative numbers
GHP (Garrett original part number): 737689-0001
GHP (Garrett original part number): 784366-0001
TCP (TurboCentras part number): GA-03-0072
TCO (TurboCentras old part number): GT20-01
GA-03-0072 - Compatibility table
| Compressor wheel GA-03-0072 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GTA2052GVK | 757608-0001 | 757608-0001, 757608-5001S | A6420900280 |
| Garrett | GTA2052GVK | 757608-0002 | 757608-0002 | -- |
| Garrett | GTA2052GVK | 757608-0003 | 757608-0003 | -- |
| Garrett | GTA2052GVK | 757608-0004 | 757608-0004 | -- |
| Garrett | GTA2052GVK | 757608-0005 | 757608-0005 | -- |
| Garrett | GTA2052GVK | 757608-0006 | 757608-0006 | -- |
| Garrett | GTA2056VK | 761399-0001 | 761399-0001, 761399-5001S | A6420900180 |
| Garrett | GTA2056VK | 761399-0002 | 761399-0002, 761399-5002S | A6420900180 |
| Garrett | GTA2056V | 763263-0005 | 763263-0005, 763263-5005S | 21354008 |
| Garrett | GTB2056VK | 764381-0001 | 764381-0001 | -- |
| Garrett | GTB2056VK | 764381-0002 | 764381-0002, 764381-5002S | A6420900880 |
| Garrett | GTB2056VK | 764381-0004 | 764381-0004, 764381-5004S | A6420900880 |
| Garrett | GTB2056VK | 764809-0001 | 764809-0001 | A6420901680 |
| Garrett | GTB2056VK | 764809-0002 | 764809-0002, 764809-5002S | A6420901680 |
| Garrett | GTB2056VK | 764809-0003 | 764809-0003 | -- |
| Garrett | GTB2056VK | 764809-0004 | 764809-0004, 764809-5004S | A6420901680 |
| Garrett | GTA2056VK | 765155-0004 | 765155-0004, 765155-5004S | A6420901480 |
| Garrett | GT2056V | 765155-0007 | 765155-0007 | A6420901480 |
| Garrett | GTA2056VK | 765155-0008 | 765155-0008, 765155-5008S | A6420901480 |
| Garrett | GTA2056VK | 765156-0003 | 765156-0003, 765156-5003S | 6420906180 |
| Garrett | GTA2056VK | 765156-0004 | 765156-0004, 765156-5004S | A6420901580 |
| Garrett | GTA2056VK | 765156-0007 | 765156-0007, 765156-5007S, 765156-9007W | 6420906180 |
| Garrett | GTA2056VK | 765156-0008 | 765156-0008, 765156-5008S | A6420901580 |
| Garrett | GTA2056VK | 770895-0001 | 770895-0001 | -- |
| Garrett | GT2056V | 770895-0002 | 770895-0002 | -- |
| Garrett | GT2056V | 770895-0007 | 770895-0007 | -- |
| Garrett | GT2056V | 770895-0008 | 770895-0008 | -- |
| Garrett | GTB2056VK | 777318-0001 | 777318-0001 | A6420908580 |
| Garrett | GTB2056VK | 777318-0002 | 777318-0002 | A6420908580 |
| Garrett | GTB2056VK | 777318-0003 | 777318-0003 | -- |
| Garrett | GTB2056 | 781743-0001 | 781743-0001 | 6420905780, A6420905780 |
| Garrett | GTB2056 | 781743-0003 | 781743-0003 | 6420905780, A6420905780 |
| Garrett | GTB2056VK | 781745-0001 | 781745-0001 | -- |
| Garrett | GTB1756VK | 800089-0001 | 800089-0001 | AH4Q6K682GA, LR022790 |
| Garrett | GTB1756VK | 800089-0003 | 800089-0003 | AH4Q6K682GB, LR022790 |
| Garrett | GTB1756VK | 802733-0004 | 802733-0004, 802733-5004S, 802733-9004S | CK5Q6K682AB, LR027187, LR044563 |
GA-03-0072 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Deep Super
A (Size A): 56.00
A1 (Size A1): 56.00
B (Size B): 43.40
C (Size C): 4.95
C1 (Size C1): 3.75
D (Size D): 31.00
E (Size E): 5.08
737689-0001, 784366-0001, GA-03-0072, GT20-01
757608-0001, 757608-5001S, A6420900280, 757608-0002, 757608-0003, 757608-0004, 757608-0005, 757608-0006, 761399-0001, 761399-5001S, A6420900180, 761399-0002, 761399-5002S, A6420900180, 21354008, 763263-0005, 763263-5005S, 764381-0001, 764381-0002, 764381-5002S, A6420900880, 764381-0004, 764381-5004S, A6420900880, 764809-0001, A6420901680, 764809-0002, 764809-5002S, A6420901680, 764809-0003, 764809-0004, 764809-5004S, A6420901680, 765155-0004, 765155-5004S, A6420901480, 765155-0007, A6420901480, 765155-0008, 765155-5008S, A6420901480, 6420906180, 765156-0003, 765156-5003S, 765156-0004, 765156-5004S, A6420901580, 6420906180, 765156-0007, 765156-5007S, 765156-9007W, 765156-0008, 765156-5008S, A6420901580, 770895-0001, 770895-0002, 770895-0007, 770895-0008, 777318-0001, A6420908580, 777318-0002, A6420908580, 777318-0003, 6420905780, 781743-0001, A6420905780, 6420905780, 781743-0003, A6420905780, 781745-0001, 800089-0001, AH4Q6K682GA, LR022790, 800089-0003, AH4Q6K682GB, LR022790, 802733-0004, 802733-5004S, 802733-9004S, CK5Q6K682AB, LR027187, LR044563
Specyfikacja
Producent
SKU
GA-03-0072
Stan
Nowy
Główny numer
GT20-01, 737689-0001, GA-03-0072, 784366-0001, CW-0258
Numer OEM
765155-0004, 765155-0007, 765155-0008, 765156-0003, 765156-0004, 765156-0007, 770895-0002, 770895-0007, 770895-0008, 777318-0001, 777318-0002, 777318-0003, 757608-0001, 761399-0001, 761399-0002, 800089-0001, 800089-0003, 781745-0001, 764381-0002, 764381-0004, 764809-0002, 764809-0004, 781743-0001, 781743-0003, 764809-0003, 764381-0001, 802733-0004, 765156-0008, 763263-0005, 757608-0002, 757608-0003, 757608-0004, 757608-0005, 757608-0006, 770895-0001, 764809-0001
Gwarancja
12 miesięcy gwarancji producenta
