Shaft and wheel for 9VA02

Dimensions of the Shaft and wheel:

Blades (Shaft & Wheel blades count): 8

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Open

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 45.20

A1 (Size A1): 36.00

B (Size B): 40.00

C (Size C): 5.51

D (Size D): 8.00

E (Size E): 5.10

H (Size H): 19.00

L (Size L): 99.00

T (Size T): M5.0X0.5L

Shaft and wheel fits to the next turbochargers:

• 9VA02 F51CAF-SQ001B 9VA15 F51CAY-SR038B FU10000698 SF500027
• 06J145703C 06J145703N 06J145704D 06J145710L 06J145701N 06J145701T 06J145702K 06J145702L 06J145702T 06J145713C 06J145713D 06J145713K 06J145713L 06J145713T 06J145722B 06J145702Q 06J145702S 06J145703T 06J145713A 06J145713F 06J145722A F50FF001A P700000204
