Compressor wheel 702549-0004
Dimensions
- A Size A
- 59.40 mm
- A1 Size A1
- 59.40 mm
- B Size B
- 42.00 mm
- C Size C
- 5.35 mm
- C1 Size C1
- 3.75 mm
- D Size D
- 32.40 mm
- E Size E
- 5.08 mm
About product
GA-03-0106 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0106
GA-03-0106 - Alternative numbers
GHP (Garrett original part number): 702549-0004
GHP (Garrett original part number): 702549-0011
GHP (Garrett original part number): 702549-0016
GHP (Garrett original part number): 702549-0020
TCP (TurboCentras part number): GA-03-0106
TCO (TurboCentras old part number): GT25-02
GA-03-0106 - Compatibility table
| Compressor wheel GA-03-0106 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GT2559V | 714306-0005 | 714306-0005 | 8972409266 |
| Garrett | GTA2559LV | 714306-0006 | 714306-0006 | 8972409267 |
| Garrett | GT2559V | 715230-0005 | 715230-0005 | -- |
| Garrett | GT2559V | 715230-0006 | 715230-0006 | -- |
| Garrett | GT2559VK | 717410-0005 | 717410-0005 | -- |
| Garrett | GT2559V | 717410-0007 | 717410-0007, 717410-5007S | 860064, 8972506762, 97250676 |
| Garrett | GT2259LS | 732409-0011 | 732409-0011, 732409-5011S | 241004252A |
| Garrett | GT2259LS | 732409-0012 | 732409-0012, 732409-5012S | 241004260A |
| Garrett | GT2259LS | 732409-0021 | 732409-0021, 732409-5021S | 241004610A |
| Garrett | GT2259LS | 732409-0022 | 732409-0022 | -- |
| Garrett | GT2259LS | 732409-0024 | 732409-0024, 732409-5024S | 17201E0450 |
| Garrett | GT2259LS | 732409-0026 | 732409-0026, 732409-5026S | 241004252A |
| Garrett | GT2259LS | 732409-0039 | 732409-0039, 732409-5039S | 17201E0451 |
| Garrett | GT2259LS | 732409-0040 | 732409-0040, 732409-5040S | 17201E0630 |
| Garrett | GT2259LS | 732409-0041 | 732409-0041, 732409-5041S | 17201EO441 |
| Garrett | GT2259LS | 732409-0042 | 732409-0042, 732409-5042S | 241004260A |
| Garrett | GT2259LS | 732409-0045 | 732409-0045, 732409-5045S | 17201E0452 |
| Garrett | GT2559S | 754743-0001 | 754743-0001, 754743-5001S | EX79525, EX79526 |
| Garrett | GT2559S | 754743-0002 | 6M34-9G438-AC, 754743-0002 | 6M34-9G438-AB |
| Garrett | GT2259LS | 761916-0003 | 761916-0003, 761916-5003S | 244000494C |
| Garrett | GT2259LS | 761916-0006 | 761916-0006, 761916-5006S | S1760E0010A |
| Garrett | GT2259LS | 761916-0007 | 761916-0007, 761916-5007S | S1760E0011 |
| Garrett | GT2259LS | 761916-0008 | 761916-0008, 761916-5008S | 17201EO520 |
| Garrett | GT2259LS | 761916-0009 | 761916-0009, 761916-5009S | S1720E0012 |
| Garrett | GT2259LS | 761916-0010 | 761916-0010, 761916-5010S | 17201-E0521 |
| Garrett | GT2259LS | 766237-0001 | 766237-0001, 766237-5001S | 1.7201E+84 |
| Garrett | GT2259LS | 766237-0004 | 766237-0004, 766237-5004S | 17201E0081 |
| Garrett | GT2259LS | 766237-0005 | 766237-0005, 766237-5005S | 17201-E0711 |
| Garrett | GT2259LS | 766237-0008 | 766237-0008, 766237-5008S | 17201-E0711 |
| Garrett | GT2559L | 786363-0004 | 786363-0004, 786363-5004S | 17201E0680A |
| Garrett | GT2259LS | 787873-0001 | 787873-0001, 787873-5001S | 17201-E0520 |
| Garrett | GT2259LS | 801644-0001 | 801644-0001, 801644-5001S | -- |
| Garrett | GT2259LS | 801801-0001 | 801801-0001 | -- |
| Garrett | GT2259LS | 801897-0001 | 801897-0001, 801897-5001S | -- |
GA-03-0106 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Deep Super
A (Size A): 59.40
A1 (Size A1): 59.40
B (Size B): 42.00
C (Size C): 5.35
C1 (Size C1): 3.75
D (Size D): 32.40
E (Size E): 5.08
702549-0004, 702549-0011, 702549-0016, 702549-0020, GA-03-0106, GT25-02
714306-0005, 8972409266, 714306-0006, 8972409267, 715230-0005, 715230-0006, 717410-0005, 717410-0007, 717410-5007S, 860064, 8972506762, 97250676, 241004252A, 732409-0011, 732409-5011S, 241004260A, 732409-0012, 732409-5012S, 241004610A, 732409-0021, 732409-5021S, 732409-0022, 17201E0450, 732409-0024, 732409-5024S, 241004252A, 732409-0026, 732409-5026S, 17201E0451, 732409-0039, 732409-5039S, 17201E0630, 732409-0040, 732409-5040S, 17201EO441, 732409-0041, 732409-5041S, 241004260A, 732409-0042, 732409-5042S, 17201E0452, 732409-0045, 732409-5045S, 754743-0001, 754743-5001S, EX79525, EX79526, 6M34-9G438-AB, 6M34-9G438-AC, 754743-0002, 244000494C, 761916-0003, 761916-5003S, 761916-0006, 761916-5006S, S1760E0010A, 761916-0007, 761916-5007S, S1760E0011, 17201EO520, 761916-0008, 761916-5008S, 761916-0009, 761916-5009S, S1720E0012, 17201-E0521, 761916-0010, 761916-5010S, 1.7201E+84, 766237-0001, 766237-5001S, 17201E0081, 766237-0004, 766237-5004S, 17201-E0711, 766237-0005, 766237-5005S, 17201-E0711, 766237-0008, 766237-5008S, 17201E0680A, 786363-0004, 786363-5004S, 17201-E0520, 787873-0001, 787873-5001S, 801644-0001, 801644-5001S, 801801-0001, 801897-0001, 801897-5001S
Specifications
Manufacturer:
SKU:
GA-03-0106
Serial number:
GA-03-0106
Main number:
GT25-02, GA-03-0106, CW-0259, 702549-0004, 702549-0011, 702549-0016, 702549-0020
OEM number:
714306-0005, 714306-0006, 717410-0007, 717410-0005, 715230-0005, 715230-0006, 754743-0001, 754743-0002, 732409-0011, 732409-0012, 732409-0021, 732409-0024, 732409-0026, 732409-0039, 732409-0040, 732409-0041, 732409-0042, 732409-0045, 761916-0003, 761916-0006, 761916-0007, 761916-0009, 761916-0010, 766237-0001, 766237-0004, 766237-0005, 766237-0008, 786363-0004, 787873-0001, 801644-0001, 801897-0001, 761916-0008, 732409-0022, 801801-0001
