Shaft and wheel for 702989-0003

Dimensions of the Shaft and wheel:

Blades (Shaft & Wheel blades count): 9

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Open

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 50.30

A1 (Size A1): 50.30

B (Size B): 42.60

C (Size C): 8.70

D (Size D): 7.88

E (Size E): 5.08

H (Size H): 25.00

L (Size L): 99.00

T (Size T): M5.0X0.8LH

Shaft and wheel fits to the next turbochargers:

• 702989-0003 702989-5003S 702989-0006 702989-5006S 704809-0003 704809-5003S 704809-0005 705104-0002 732409-0011 732409-5011S 732409-0012 732409-5012S 732409-0021 732409-5021S 732409-0022 732409-0024 732409-5024S 732409-0026 732409-5026S 732409-0039 732409-5039S 732409-0040 732409-5040S 732409-0041 732409-5041S 732409-0042 732409-5042S 732409-0045 732409-5045S 732610-0009736210-0002 736210-5002S 736210-0003 736210-5003S 736210-0005 736210-5005S 736210-0006 736210-5006S 736210-0007 736210-5007S 736210-0009 736210-5009S 736210-0010 736210-5010S 738769-0001 738769-5001S 738769-0002 738769-5002S 738769-0003 738769-5003S 738769-0004 738769-5004S 738769-0005 738769-5005S 738769-0006 738769-5006S 738769-0007 738769-5007S 738769-0009 738769-5009S 738769-0010 738769-5010S 738769-0012 738769-5012S 738769-0014 738769-0015 738769-5015S 741157-0001 741157-5001S 754958-0001 754958-5001S 755310-0001 755310-5001S 759638-0001 759638-5001S 759638-0002 759638-5002S 759638-0003 759638-5003S 759638-0004 759638-5004S 759638-0006 759638-5006S 759638-0007 759638-5007S 761916-0003 761916-5003S 761916-0006 761916-5006S 761916-0007 761916-5007S 761916-0008 761916-5008S 761916-0009 761916-5009S 761916-0010 761916-5010S 761916-0011 761916-5011S 761916-0012 761916-5012S 762931-0001 762931-5001S 762931-0002 762931-5002S 762931-0003 762931-5003S 762931-0004 762931-5004S 762931-0005 762931-5005S 762931-0006 762931-5006S 762931-0011 762931-5011S 762931-0012 762931-0015 762931-5015S 766237-0001 766237-5001S 766237-0002 766237-5002S 766237-0003 766237-5003S 766237-0004 766237-5004S 766237-0005 766237-5005S 766237-0008 766237-5008S 766237-0009 766237-5009S 787873-0001 787873-5001S 787876-0001 797648-0001 797648-5001S 797648-0003 797648-5003S 797648-0005 797648-5005S 801644-0001 801644-5001S 801801-0001 801897-0001 801897-5001S 806883-0001 806883-5001S 806883-0003 806883-5003S 806883-0005 806883-5005S 806883-0006 806883-5006S 878998-0001 878998-5001S 878998-0002 878998-5002S 878998-0003 878998-5003S
• 4891639 504094261 1118010-C012 1118010-55D 2674A332 241004252A 241004260A 241004610A 17201E0450 241004252A 17201E0451 17201E0630 17201EO441 241004260A 17201E0452 1118300DQ 1118300SD 1118300SZ 1118300TAR1118300SBJMTL 1118300DL 1118300AAD E049339000082 E049339000096 EO49339000128 E049339000054 E049339000050 E049339000055 E049339000056 E049339000167 E049339000186 E049339000204 E049339000257 14411-7T600 1378564 504094449 1008200FA020 1008200FA060 1008200FA040 1008200FA011 1008200FA100 1008200FA051 244000494C S1760E0010A S1760E0011 17201EO520 S1720E0012 17201-E0521 S1760E0014 17201E0522 32006047 320/06081 320/06079 320/06083 320/06084 320/06094 320/06159 320/06157 32006157 1.7201E+84 17201-E0061 17201-E0062 1 72E+85 17201-E0711 17201-E0711 17201E0713 17201-E0520 504379020 5801397254 580155886 17201E0801 17201E0802 17201E0803 17201EW032 5802746681 5802741359 5801558886 5802741363
