Compressor wheel 54409700024
Dimensions
- A Size A
- 45.00 mm
- A1 Size A1
- 46.50 mm
- B Size B
- 35.10 mm
- C Size C
- 3.70 mm
- C1 Size C1
- 2.80 mm
- D Size D
- 24.70 mm
- E Size E
- 4.11 mm
About product
BW-03-0004 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: BW-03-0004
BW-03-0004 - Alternative numbers
BWP (BorgWarner original part number): 1645 123 2000
TCO (TurboCentras old part number): BV40-01B
TCP (TurboCentras part number): BW-03-0004
BW-03-0004 - Compatibility table
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
|---|---|---|---|---|
| BorgWarner | BV40 | 54409700024 | 5440 970 0024 | 8513635 |
| BorgWarner | BV40 | 54409700025 | 5440 970 0025 | 8513640 |
| BorgWarner | BV40 | 54409700031 | 5440 970 0031 | 8513635 |
| BorgWarner | BV40 | 54409700032 | 5440 970 0032 | 8513640 |
| BorgWarner | BV40 | 54409700033 | 5440 970 0033 | 8513635 |
| BorgWarner | BV40 | 54409700034 | 5440 970 0034 | 8513640 |
| BorgWarner | BV40 | 54409700038 | 5440 970 0038 | 8513635 |
| BorgWarner | BV40 | 54409700039 | 5440 970 0039 | 8513640 |
| BorgWarner | BV40 | 54409700041 | 5440 970 0041 | 8513635 |
| BorgWarner | BV40 | 54409700042 | 5440 970 0042 | 8513640 |
| BorgWarner | BV40 | 54409700043 | 5440 970 0043, 5440 998 0043 | 11658513635, 8513635 |
| BorgWarner | BV40 | 54409700044 | 5440 970 0044 | 8513640, 851364006 |
| BorgWarner | BV40 | 54409700046 | 5440 970 0046, 5440 998 0046 | 11658513640, 1165851364107, 8513640 |
| BorgWarner | BV40 | 54409710043 | 5440 971 0043, 5440 998 0043 | 11658513636, 1165851363608, 8513636 |
| BorgWarner | BV40 | 54409710046 | 5440 971 0046, 5440 998 0046 | 11658513641, 8513641 |
| BorgWarner | BV40 | 54409980043 | 5440 970 0043, 5440 971 0043, 5440 998 0043 | 11658513635, 11658513636, 8513635, 8513636 |
| BorgWarner | BV40 | 54409980046 | 5440 970 0046, 5440 971 0046, 5440 998 0046 | 11658513640, 11658513641, 8513640, 8513641 |
BW-03-0004 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Super
A (Size A): 45.00
A1 (Size A1): 46.50
B (Size B): 35.10
C (Size C): 3.70
C1 (Size C1): 2.80
D (Size D): 24.70
E (Size E): 4.11
1645-123-2000, BV40-01B, BW-03-0004
54409980046, 54409710046, 54409700046, 54409700044, 54409700043, 54409700042, 54409700041, 54409700039, 54409700038, 54409700034, 54409700033, 54409700032, 54409700031, 54409700025, 54409700024, 5440 970 0024, 8513635, 5440 970 0025, 8513640, 5440 970 0031, 8513635, 5440 970 0032, 8513640, 5440 970 0033, 8513635, 5440 970 0034, 8513640, 5440 970 0038, 8513635, 5440 970 0039, 8513640, 5440 970 0041, 8513635, 5440 970 0042, 8513640, 5440 970 0043, 8513635, 5440 970 0044, 8513640, 5440 970 0046, 5440 971 0046, 5440 998 0046, 8513640, 8513641
Specifications
Manufacturer:
SKU:
BW-03-0004
Serial number:
BW-03-0004
Main number:
BW-03-0004, BV40-01B, 1645 123 2000, CW-1390B
OEM number:
54409700025, 54409700032, 54409700034, 54409700039, 54409700042, 54409700044, 54409980046, 54409980043, 54409700041, 54409700038, 54409700033, 54409700031, 54409700024
