Крыльчатка компрессора 54409700024
Размеры
- A Size A
- 45.00 mm
- A1 Size A1
- 46.50 mm
- B Size B
- 35.10 mm
- C Size C
- 3.70 mm
- C1 Size C1
- 2.80 mm
- D Size D
- 24.70 mm
- E Size E
- 4.11 mm
О товаре
BW-03-0004 - Крыльчатка компрессора
Бренд: TurboCentras
TurboCentras Артикул: BW-03-0004
BW-03-0004 - Альтернативные номера
BWP (BorgWarner original part number): 1645 123 2000
TCO (TurboCentras old part number): BV40-01B
TCP (TurboCentras part number): BW-03-0004
BW-03-0004 - Таблица совместимости
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
|---|---|---|---|---|
| BorgWarner | BV40 | 54409700024 | 5440 970 0024 | 8513635 |
| BorgWarner | BV40 | 54409700025 | 5440 970 0025 | 8513640 |
| BorgWarner | BV40 | 54409700031 | 5440 970 0031 | 8513635 |
| BorgWarner | BV40 | 54409700032 | 5440 970 0032 | 8513640 |
| BorgWarner | BV40 | 54409700033 | 5440 970 0033 | 8513635 |
| BorgWarner | BV40 | 54409700034 | 5440 970 0034 | 8513640 |
| BorgWarner | BV40 | 54409700038 | 5440 970 0038 | 8513635 |
| BorgWarner | BV40 | 54409700039 | 5440 970 0039 | 8513640 |
| BorgWarner | BV40 | 54409700041 | 5440 970 0041 | 8513635 |
| BorgWarner | BV40 | 54409700042 | 5440 970 0042 | 8513640 |
| BorgWarner | BV40 | 54409700043 | 5440 970 0043, 5440 998 0043 | 11658513635, 8513635 |
| BorgWarner | BV40 | 54409700044 | 5440 970 0044 | 8513640, 851364006 |
| BorgWarner | BV40 | 54409700046 | 5440 970 0046, 5440 998 0046 | 11658513640, 1165851364107, 8513640 |
| BorgWarner | BV40 | 54409710043 | 5440 971 0043, 5440 998 0043 | 11658513636, 1165851363608, 8513636 |
| BorgWarner | BV40 | 54409710046 | 5440 971 0046, 5440 998 0046 | 11658513641, 8513641 |
| BorgWarner | BV40 | 54409980043 | 5440 970 0043, 5440 971 0043, 5440 998 0043 | 11658513635, 11658513636, 8513635, 8513636 |
| BorgWarner | BV40 | 54409980046 | 5440 970 0046, 5440 971 0046, 5440 998 0046 | 11658513640, 11658513641, 8513640, 8513641 |
BW-03-0004 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Super
A (Size A): 45.00
A1 (Size A1): 46.50
B (Size B): 35.10
C (Size C): 3.70
C1 (Size C1): 2.80
D (Size D): 24.70
E (Size E): 4.11
1645-123-2000, BV40-01B, BW-03-0004
16451232000, 1645 123 2000, BV40-01B, BW-03-0004
54409980046, 54409710046, 54409700046, 54409700044, 54409700043, 54409700042, 54409700041, 54409700039, 54409700038, 54409700034, 54409700033, 54409700032, 54409700031, 54409700025, 54409700024, 5440 970 0024, 8513635, 5440 970 0025, 8513640, 5440 970 0031, 8513635, 5440 970 0032, 8513640, 5440 970 0033, 8513635, 5440 970 0034, 8513640, 5440 970 0038, 8513635, 5440 970 0039, 8513640, 5440 970 0041, 8513635, 5440 970 0042, 8513640, 5440 970 0043, 8513635, 5440 970 0044, 8513640, 5440 970 0046, 5440 971 0046, 5440 998 0046, 8513640, 8513641
Характеристики
Производитель:
SKU:
BW-03-0004
Серийный номер:
BW-03-0004
Основной номер:
BW-03-0004, BV40-01B, 1645 123 2000, CW-1390B
OEM-номер:
54409700025, 54409700032, 54409700034, 54409700039, 54409700042, 54409700044, 54409980046, 54409980043, 54409700041, 54409700038, 54409700033, 54409700031, 54409700024
