Sealing plate for 079145704F

IH-08-0028 - Part Dimensions and Features

Type (Back plate type): Outside

Trim (Back plate trim): Superback

A (Size A): 119.40

B (Size B): 106.05

C (Size C): 59.40

D (Size D): 10.00

E (Size E): 12.70

IH-08-0028 - Used in turbines:

079145703F, 9VA20, 079145703M, 079145703Q, 079145704F, 9VA19, 079145704M, 079145704Q, 079145721A, 079145722A

Data updated: 2025-03-03 14:40:38
