Shaft and wheel for 49135-07400

Dimensions of the Shaft and wheel:

Blades (Shaft & Wheel blades count): 9

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Full

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 43.20

A1 (Size A1): 43.20

B (Size B): 37.70

C (Size C): 7.45

D (Size D): 7.00

E (Size E): 5.00

H (Size H): 17.00

L (Size L): 93.00

T (Size T): M5.0X0.8LH

Shaft and wheel fits to the next turbochargers:

• 49135-07400 49135-07401 49135-07410 49335-01010 49335-01011 49335-01012 49335-01013 49335-01014 49335-01100 49335-01101 49335-01102 49335-01103 49335-01120 49335-01121 49335-01122 49335-01123 49335-01300
• 28231-27750 28231-27760 1515A215 1515A224 1515A238 1515A272
