Shaft and wheel for 452191-0001

Dimensions of the Shaft and wheel:

Blades (Shaft & Wheel blades count): 12

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Slender

Back (Shaft & Wheel back type): Open

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 47.00

A1 (Size A1): 47.00

B (Size B): 40.00

C (Size C): 6.30

D (Size D): 7.88

E (Size E): 5.08

H (Size H): 20.00

L (Size L): 92.50

T (Size T): M5.0X0.8LH

Shaft and wheel fits to the next turbochargers:

• 452191-0001 452191-0002 452191-0003 452191-0004 452191-5004S 452191-0005 452191-0006 452191-0007 452191-0008 452191-0011 452222-0001 452222-0002 452222-0003 452222-3 452222-0004 452222-0005 452222-0006 452222-0007 452222-0008 452222-0009 452239-0003 452239-5003S 452239-0005 452239-5005S 452239-0006 452239-5006S 452239-0008 452239-5008S 452239-0009 452239-5009S 452239-5009W 452264-0001 452264-0002 452264-0003 452271-0001 452271-0002 452301-0001 452301-0002 452301-0003 454126-0002 705668-0001 708257-0001 708257-5001S 708258-0001 708258-5001S 714334-0001 714334-5001S 714334-0002 714334-5002S 715330-0001 715330-5001S 715645-0001 715645-0002 715645-5002S 715645-0004 715645-5004S 717264-0001 721843-0001 721843-5001S 722687-0001 722687-5001S 723190-0003 723190-5003S 723190-0006 723190-5006S 724249-0001 727262-0001 727262-5001S 727262-0002 727262-5002S 727262-0003 727262-5003S 727262-0004 727262-5004S 727262-0005 727262-5005S 727262-0006 727262-5006S 727262-0007 727262-5007S 727262-0008 727262-5008S 727262-0009 727262-5009S 727263-0001 727263-0002 727263-5002S 727264-0001 727264-5001S 727264-5001W 727264-0002 727264-5002S 727264-0003 727264-5003S 727264-0004 727264-5004S 727264-0005 727264-5005S 727264-0006 727264-5006S 727264-0007 727264-5007S 727264-0008 727264-5008S 727264-0009 727264-5009S 727264-0010 727264-0016 727265-0001 727265-0002 727265-5002S 727265-0003 727266-0001 727266-5001S 727266-5001W 727266-0002 727266-5002S 727266-0003 727266-5003S
• 2674A089 2674A304 2674A305 2674A098 2674A315 2674A313 2674A314 2674A339 2674A341 PMF100460 PMF000040 LR017315 79050 79054 467916880 467916880 905292010075 14411G2408 1441169T91 79159 14411-7F411 144117F411 9.0529.20.1.007402 2674A351 2674A352 2674A353 2674A354 2674A355 2674A356 2674A357 2674A358 2674A359
