Compressor wheel 297710
Dimensions
- A Size A
- 49.00 mm
- A1 Size A1
- 49.00 mm
- B Size B
- 36.45 mm
- C Size C
- 4.75 mm
- C1 Size C1
- 3.85 mm
- D Size D
- 29.60 mm
- E Size E
- 5.10 mm
About product
IH-03-0040 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: IH-03-0040
IH-03-0040 - Alternative numbers
TCP (TurboCentras part number): IH-03-0040
TCO (TurboCentras old part number): RHV4-00
IH-03-0040 - Compatibility table
| Compressor wheel IH-03-0040 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| IHI | RHF5 | 297710 | 297710 | 1044T12-2649C15 |
| IHI | RHF5 | 297711 | 297711 | -- |
| IHI | RHF5 | 300684 | 300684 | 1403030071E20 |
| IHI | RHF5 | 302369 | 302369 | -- |
| IHI | RHV4-T39 | 9VB01 | 9VB01, V41VEG-SR022B | 11657812321, 1165781232102, 1165781232103, 11658506722, 11658513122, 11658513123, 11658513124, 11658518204, 1165851820402, 11658518205, 1165851820502, 7812321, 7812321.03, 781232102, 781232103, 8506722, 8513122, 8513123, 8513124, 8518204, 8518204.02, 851820402, 8518205, 8518205.02, 851820502 |
| IHI | RHV4-T39 | 9VB02 | 9VB02 | 1165851237902, 1165851237903, 1165851237907, 11658512454, 8512379.02, 8512379.03, 8512379.07, 851237902, 851237903, 851237907, 8512454 |
IH-03-0040 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 49.00
A1 (Size A1): 49.00
B (Size B): 36.45
C (Size C): 4.75
C1 (Size C1): 3.85
D (Size D): 29.60
E (Size E): 5.10
IH-03-0040, RHV4-00
1044T12-2649C15, 297710, 297711, 1403030071E20, 300684, 302369, 11657812321, 1165781232102, 1165781232103, 11658506722, 11658513122, 11658513123, 11658513124, 11658518204, 1165851820402, 11658518205, 1165851820502, 7812321, 7812321.03, 781232102, 781232103, 8506722, 8513122, 8513123, 8513124, 8518204, 8518204.02, 851820402, 8518205, 8518205.02, 851820502, 9VB01, V41VEG-SR022B, 1165851237902, 1165851237903, 1165851237907, 11658512454, 8512379.02, 8512379.03, 8512379.07, 851237902, 851237903, 851237907, 8512454, 9VB02
Specifications
Manufacturer:
SKU:
IH-03-0040
Serial number:
IH-03-0040
Main number:
RHV4-00, IH-03-0040, CW-0748
OEM number:
9VB02, 297710, 297711, 300684, 302369, 9VB01
