Compressor wheel 2837411
Dimensions
- A Size A
- 73.00 mm
- A1 Size A1
- 73.00 mm
- B Size B
- 44.00 mm
- C Size C
- 5.20 mm
- C1 Size C1
- 5.00 mm
- D Size D
- 39.00 mm
- E Size E
- 7.00 mm
About product
HO-03-0015 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: HO-03-0015
HO-03-0015 - Alternative numbers
HSP (Holset original part number): 3599669
TCO (TurboCentras old part number): H1C-02
TCP (TurboCentras part number): HO-03-0015
HO-03-0015 - Compatibility table
| Compressor wheel HO-03-0015 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Holset | HX30W | 2837411 | 2837411, 2837412, 4033983, 4033983H | 2881904 |
| Holset | HX30W | 3538981 | 3538981, 3538982 | 3806260 |
| Holset | HX30W | 3590493 | 3590493, 3590494 | -- |
| Holset | HX30W | 3590496 | 3590496, 3590497 | -- |
| Holset | HX30W | 3592311 | 3592311, 3592312, 3592312H | -- |
| Holset | HX30W | 3592315 | 3592315, 3592316, 3592316H | 3800986 |
| Holset | HX30W | 3592317 | 3592317, 3592318, 3598814, 4033397, 4033397H | 3800998 |
| Holset | HX30W | 3598047 | 3598047, 3598048, 4033984, 4033984H | -- |
| Holset | HX30W | 3599064 | 3599064, 3599065 | -- |
| Holset | HX30W | 3599240 | 3599240, 3599253 | -- |
| Holset | HX30W | 3599599 | 3599599, 3599600 | -- |
| Holset | HX30 | 4039338 | 2835399, 4039338, 4039339, 4039339H | -- |
| Holset | HX30W | 4040353 | 2839318, 2843727, 4033321, 4033321H, 4040353, 4040382, 4040383, 4045759 | A3960907 |
| Holset | HX30W | 4045959 | 4045959, 4045960 | -- |
HO-03-0015 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 73.00
A1 (Size A1): 73.00
B (Size B): 44.00
C (Size C): 5.20
C1 (Size C1): 5.00
D (Size D): 39.00
E (Size E): 7.00
3599669, H1C-02, HO-03-0015
2837411, 2837412, 2881904, 4033983, 4033983H, 3538981, 3538982, 3806260, 3590493, 3590494, 3590496, 3590497, 3592311, 3592312, 3592312H, 3592315, 3592316, 3592316H, 3800986, 3592317, 3592318, 3598814, 3800998, 4033397, 4033397H, 3598047, 3598048, 4033984, 4033984H, 3599064, 3599065, 3599240, 3599253, 3599599, 3599600, 2835399, 4039338, 4039339, 4039339H, 2839318, 2843727, 4033321, 4033321H, 4040353, 4040382, 4040383, 4045759, A3960907, 4045959, 4045960
Specifications
Manufacturer:
SKU:
HO-03-0015
Serial number:
HO-03-0015
Main number:
H1C-02, 3599669, HO-03-0015, CW-0528
OEM number:
2837411, 3538981, 3590493, 3590496, 3592311, 3592315, 3592317, 3598047, 3599064, 3599240, 3599599, 4039338, 4040353, 4045959
