Compressor wheel 2835430
Dimensions
- A Size A
- 99.00 mm
- A1 Size A1
- 99.00 mm
- B Size B
- 67.00 mm
- C Size C
- 6.40 mm
- C1 Size C1
- 6.25 mm
- D Size D
- 45.00 mm
- E Size E
- 8.00 mm
About product
HO-03-0012 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: HO-03-0012
HO-03-0012 - Alternative numbers
HSP (Holset original part number): 3593686
HSP (Holset original part number): 4040740
TCP (TurboCentras part number): HO-03-0012
TCO (TurboCentras old part number): HX50-02
HO-03-0012 - Compatibility table
| Compressor wheel HO-03-0012 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Holset | HX55 | 3590273 | 3590273, 3590273, 3591079, 4031143, 4031143H | 3165218, 8113422 |
| Holset | HX55 | 3594236 | 3594236, 3594238, 3594239 | 1443190, 1443191 |
| Holset | HX55 | 3597728 | 3597728, 3597729, 3597730 | 1484886, 1484887 |
| Holset | HX52 | 4037053 | 4031118, 4031118H, 4031118HX, 4037053, 4037054, 4037936 | 1534695, 1547763 |
| Holset | HX52 | 4045196 | 4045196, 4045201 | 1778616 |
HO-03-0012 - Part Properties
Blades (Compressor wheel blades count): 7/7
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 99.00
A1 (Size A1): 99.00
B (Size B): 67.00
C (Size C): 6.40
C1 (Size C1): 6.25
D (Size D): 45.00
E (Size E): 8.00
3593686, 4040740, HO-03-0012, HX50-02
3165218, 3590273, 3590273, 3591079, 4031143, 4031143H, 8113422, 1443190, 1443191, 3594236, 3594238, 3594239, 1484886, 1484887, 3597728, 3597729, 3597730, 1534695, 1547763, 4031118, 4031118H, 4031118HX, 4037053, 4037054, 4037936, 1778616, 4045196, 4045201
Specifications
Manufacturer:
SKU:
HO-03-0012
Serial number:
HO-03-0012
Main number:
HX50-02, HO-03-0012, 3593686, 4040740, CW-0569
OEM number:
3594236, 3597728, 4037053, 4045196, 3590273
