Compressor wheel 454150-0001
Dimensions
- A Size A
- 52.00 mm
- A1 Size A1
- 52.00 mm
- B Size B
- 36.80 mm
- C Size C
- 4.70 mm
- C1 Size C1
- 2.40 mm
- D Size D
- 26.10 mm
- E Size E
- 6.00 mm
About product
GA-03-0146 - Крыльчатка компрессора
Бренд: TurboCentras
TurboCentras Артикул: GA-03-0146
GA-03-0146 - Альтернативные номера
GHP (Garrett original part number): 436131-0010
TCP (TurboCentras part number): GA-03-0146
GA-03-0146 - Таблица совместимости
| Крыльчатка компрессора GA-03-0146 - Совместимые турбокомпрессоры | ||||
|---|---|---|---|---|
| ПРОИЗВОДИТЕЛЬ ТУРБИНЫ | МОДЕЛЬ ТУРБИНЫ | АРТИКУЛ ТУРБИНЫ | TURBO PART NUMBER | OE НОМЕР ТУРБИНЫ |
| Garrett | TD2503 | 454150-0001 | 454150-0001 | -- |
| Garrett | TD2503 | 454150-0002 | 454150-0002 | -- |
| Garrett | TD2503 | 454150-0003 | 454150-0003, 454150-5003S | 46520528, 46763887 |
| Garrett | TD2503 | 454150-0004 | 454150-0004, 454150-5004S | 46522417, 46763886 |
| Garrett | TD2503 | 701900-0001 | 701900-0001, 701900-5001S | 46528420 |
GA-03-0146 - Свойства детали
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 52.00
A1 (Size A1): 52.00
B (Size B): 36.80
C (Size C): 4.70
C1 (Size C1): 2.40
D (Size D): 26.10
E (Size E): 6.00
436131-0010, GA-03-0146
454150-0001, 454150-0002, 454150-0003, 454150-5003S, 46520528, 46763887, 454150-0004, 454150-5004S, 46522417, 46763886, 46528420, 701900-0001, 701900-5001S
Specifications
Manufacturer
SKU
GA-03-0146
Condition
New
Main number
GA-03-0146, CW-0353-1, 436131-0010
OEM number
454150-0003, 454150-0004, 454150-0002, 454150-0001, 701900-0001
Warranty
12 months of manufacturer warranty
Delivery and Payment
Components
11 parts
