Compressor wheel 761002-0001
Dimensions
- A Size A
- 49.50 mm
- A1 Size A1
- 49.50 mm
- B Size B
- 34.70 mm
- C Size C
- 4.79 mm
- C1 Size C1
- 4.00 mm
- D Size D
- 26.50 mm
- E Size E
- 5.08 mm
About product
GA-03-0066 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0066
GA-03-0066 - Alternative numbers
GHP (Garrett original part number): 761002-0001
TCP (TurboCentras part number): GA-03-0066
TCO (TurboCentras old part number): GT17-10B
GA-03-0066 - Compatibility table
| Compressor wheel GA-03-0066 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GT3067S+GTB1749VK | 805713-0004 | 805713-0004, 805713-5004S | 059145061L |
| Garrett | GT3067S+GTB1749VK | 805713-0007 | 805713-0007, 805713-5007S | 059145061Q |
| Garrett | GT3067S+GTB1749VK | 805713-0009 | 805713-0009, 805713-5009S | 059145061AD |
| Garrett | GT3067S | 805714-0004 | 805714-0004 | 059145653L |
| Garrett | GT3067S | 805714-0007 | 805714-0007 | 059145653Q |
GA-03-0066 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Deep Super
A (Size A): 49.50
A1 (Size A1): 49.50
B (Size B): 34.70
C (Size C): 4.79
C1 (Size C1): 4.00
D (Size D): 26.50
E (Size E): 5.08
761002-0001, GA-03-0066, GT17-10B
059145061L, 805713-0004, 805713-5004S, 059145061Q, 805713-0007, 805713-5007S, 059145061AD, 805713-0009, 805713-5009S, 059145653L, 805714-0004, 059145653Q, 805714-0007
Specifications
Manufacturer:
SKU:
GA-03-0066
Serial number:
GA-03-0066
Main number:
761002-0001, GT17-10B, GA-03-0066, CW-1321B
OEM number:
805714-0004, 805714-0007, 805713-0004, 805713-0007, 805713-0009
