Compressor wheel 742110-0002
Dimensions
- A Size A
- 46.00 mm
- A1 Size A1
- 46.00 mm
- B Size B
- 32.60 mm
- C Size C
- 3.70 mm
- C1 Size C1
- 4.00 mm
- D Size D
- 25.20 mm
- E Size E
- 2.08 mm
About product
GA-03-0045 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0045
GA-03-0045 - Alternative numbers
GHP (Garrett original part number): 737686-0003
TCP (TurboCentras part number): GA-03-0045
TCO (TurboCentras old part number): GT15-17
GA-03-0045 - Compatibility table
| Compressor wheel GA-03-0045 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GTB1746VK | 742110-0003 | 742110-0003 | 4M5Q6K682AF |
| Garrett | GT1746V | 742110-0004 | 742110-0004, 742110-5004S | 4M5Q-6K682-AD, 4M5Q6K682AD |
| Garrett | GTB1746VK | 742110-0005 | 742110-0005 | 4M5Q6K682AF |
| Garrett | GT1746V | 742110-0006 | 742110-0006, 742110-5006S | 4M5Q-6K682-AF, 4M5Q6K682AF |
| Garrett | GT1746V | 742110-0007 | 742110-0007, 742110-5007S, 742110-9007S | 4M5Q-6K682-AG, 4M5Q6K682AG |
| Garrett | GTB1746VK | 742110-0015 | 742110-0015 | -- |
| Garrett | GTB1746VK | 758532-0012 | 758532-0012, 758532-5012S | 6G9Q-6K682-AC, 6G9Q6K682AC |
| Garrett | GTB1746VK | 758532-0019 | 758532-0019, 758532-5019S | 6G9Q-6K682-AC, 6G9Q-6K682-AD, 6G9Q6K682AC, 6G9Q6K682AD |
| Garrett | GTB1746V | 763647-0014 | 763647-0014, 763647-5014S | 1453914, 1464596, 1478634, 1521485, 1567329, 4M5Q6K682AD, 4M5Q6K682AF, 7G9Q6K682BA, 7G9Q6K682BB, 7G9Q6K682BC, 7G9Q6K682BD |
| Garrett | GTB1746V | 763647-0019 | 763647-0019, 763647-5019S | 1453914, 1464596, 1478634, 1521485, 1567329, 4M5Q6K682AD, 4M5Q6K682AF, 7G9Q6K682BA, 7G9Q6K682BB, 7G9Q6K682BC, 7G9Q6K682BD |
| Garrett | GTB1746V | 763647-0021 | 763647-0021, 763647-5021S, 763647-5021W, 763647-9021W | 7G9Q6K682BD |
| Garrett | GTB1546V | 779591-0001 | 779591-0001, 779591-5001S, 779591-9004W | 8980536743 |
| Garrett | GTB1546V | 779591-0002 | 779591-0002, 779591-5002S, 779591-9004W | 8980536744 |
| Garrett | GTB1546V | 779591-0004 | 779591-0004, 779591-5004S | 98053674 |
GA-03-0045 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Deep Super
A (Size A): 46.00
A1 (Size A1): 46.00
B (Size B): 32.60
C (Size C): 3.70
C1 (Size C1): 4.00
D (Size D): 25.20
E (Size E): 2.08
737686-0003, GA-03-0045, GT15-17
4M5Q6K682AF, 742110-0003, 4M5Q-6K682-AD, 4M5Q6K682AD, 742110-0004, 742110-5004S, 4M5Q6K682AF, 742110-0005, 4M5Q-6K682-AF, 4M5Q6K682AF, 742110-0006, 742110-5006S, 4M5Q-6K682-AG, 4M5Q6K682AG, 742110-0007, 742110-5007S, 742110-9007S, 742110-0015, 6G9Q-6K682-AC, 6G9Q6K682AC, 758532-0012, 758532-5012S, 6G9Q-6K682-AC, 6G9Q-6K682-AD, 6G9Q6K682AC, 6G9Q6K682AD, 758532-0019, 758532-5019S, 1453914, 1464596, 1478634, 1521485, 1567329, 4M5Q6K682AD, 4M5Q6K682AF, 763647-0014, 763647-5014S, 7G9Q6K682BA, 7G9Q6K682BB, 7G9Q6K682BC, 7G9Q6K682BD, 1453914, 1464596, 1478634, 1521485, 1567329, 4M5Q6K682AD, 4M5Q6K682AF, 763647-0019, 763647-5019S, 7G9Q6K682BA, 7G9Q6K682BB, 7G9Q6K682BC, 7G9Q6K682BD, 763647-0021, 763647-5021S, 763647-5021W, 763647-9021W, 7G9Q6K682BD, 779591-0001, 779591-5001S, 779591-9004W, 8980536743, 779591-0002, 779591-5002S, 779591-9004W, 8980536744, 779591-0004, 779591-5004S, 98053674
Specifications
Manufacturer:
SKU:
GA-03-0045
Serial number:
GA-03-0045
Main number:
GT15-17, 737686-0003, GA-03-0045, CW-0374
OEM number:
742110-0004, 742110-0006, 742110-0007, 758532-0012, 763647-0014, 763647-0019, 763647-0021, 779591-0001, 779591-0002, 758532-0019, 779591-0004, 742110-0003, 742110-0005, 742110-0015
