Compressor wheel 704771-0001
Dimensions
- A Size A
- 44.00 mm
- A1 Size A1
- 44.00 mm
- B Size B
- 32.60 mm
- C Size C
- 3.60 mm
- C1 Size C1
- 2.40 mm
- D Size D
- 22.60 mm
- E Size E
- 5.08 mm
About product
GA-03-0042 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0042
GA-03-0042 - Alternative numbers
GHP (Garrett original part number): 704771-0001
GHP (Garrett original part number): 704771-0008
TCP (TurboCentras part number): GA-03-0042
TCO (TurboCentras old part number): GT15-14
GA-03-0042 - Compatibility table
| Compressor wheel GA-03-0042 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GT1544S | 708866-0002 | 708866-0002 | 24461826 |
| Garrett | GT1544S | 708867-0002 | 708867-0002, 708867-5002S | 24461825 |
GA-03-0042 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 44.00
A1 (Size A1): 44.00
B (Size B): 32.60
C (Size C): 3.60
C1 (Size C1): 2.40
D (Size D): 22.60
E (Size E): 5.08
704771-0001, 704771-0008, GA-03-0042, GT15-14
24461826, 708866-0002, 24461825, 708867-0002, 708867-5002S
Specifications
Manufacturer:
SKU:
GA-03-0042
Serial number:
GA-03-0042
Main number:
GT15-14, 704771-0001, GA-03-0042, CW-0193, 704771-0008
OEM number:
708866-0002, 708867-0002
