Compressor wheel 778401-0004
Dimensions
- A Size A
- 44.00 mm
- A1 Size A1
- 44.00 mm
- B Size B
- 29.50 mm
- C Size C
- 2.90 mm
- C1 Size C1
- 4.00 mm
- D Size D
- 24.20 mm
- E Size E
- 4.08 mm
About product
GA-03-0020 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0020
GA-03-0020 - Alternative numbers
TCP (TurboCentras part number): GA-03-0020
TCO (TurboCentras old part number): GT14-07
GA-03-0020 - Compatibility table
| Compressor wheel GA-03-0020 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GT1444Z | 778401-0004 | 778401-0004 | AH2Q6K682AC, LR013205 |
| Garrett | GT1444Z | 778401-0005 | 778401-0005 | AH2Q6K682AD, AH2Q6K682AF, LR013205, LR021254, LR032370, LR038620, LR056370, LR063777 |
| Garrett | GT1444Z+VTC | 778401-0006 | 778401-0006 | AH2Q6K682AE, LR032370 |
| Garrett | GT1444Z | 778401-0007 | 778401-0007 | LR029236 |
| Garrett | GT1444Z | 778401-0008 | 778401-0008 | AH2Q6K682AF, LR038620 |
| Garrett | GT1444Z VTC | 778401-0010 | 778401-0010 | AH2Q6K682AH |
| Garrett | GT1444Z+VTC | 778401-0011 | 778401-0011 | AH2Q6K682AJ, LR063777 |
| Garrett | GT1444Z+VTC | 778401-0012 | 778401-0012 | AH2Q6K682AK, LR063777 |
| Garrett | GT1444Z+VTC | 778402-0004 | 778402-0004, 778402-5004S | 02C2C40365, AX2Q6K682BC |
| Garrett | GT1444Z+VTC | 778402-0005 | 778402-0005, 778402-5005S | AX2Q6K682BD |
| Garrett | GT1444Z+VTC | 778402-0006 | 778402-0006, 778402-5006S | AX2Q6K682BE |
| Garrett | GT1444Z+VTC | 778402-0008 | 778402-0008, 778402-5008S | AX2Q6K682BF |
| Garrett | GT1444Z+VTC | 778402-0010 | 778402-0010, 778402-5010S | AX2Q6K682BH |
GA-03-0020 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Deep Super
A (Size A): 44.00
A1 (Size A1): 44.00
B (Size B): 29.50
C (Size C): 2.90
C1 (Size C1): 4.00
D (Size D): 24.20
E (Size E): 4.08
GA-03-0020, GT14-07
778401-0004, AH2Q6K682AC, LR013205, 778401-0005, AH2Q6K682AD, AH2Q6K682AF, LR013205, LR021254, LR032370, LR038620, LR056370, LR063777, 778401-0006, AH2Q6K682AE, LR032370, 778401-0007, LR029236, 778401-0008, AH2Q6K682AF, LR038620, 778401-0010, AH2Q6K682AH, 778401-0011, AH2Q6K682AJ, LR063777, 778401-0012, AH2Q6K682AK, LR063777, 02C2C40365, 778402-0004, 778402-5004S, AX2Q6K682BC, 778402-0005, 778402-5005S, AX2Q6K682BD, 778402-0006, 778402-5006S, AX2Q6K682BE, 778402-0008, 778402-5008S, AX2Q6K682BF, 778402-0010, 778402-5010S, AX2Q6K682BH
Specifications
Manufacturer:
SKU:
GA-03-0020
Serial number:
GA-03-0020
Main number:
GT14-07, CW-0492, GA-03-0020
OEM number:
778401-0004, 778401-0005, 778401-0006, 778401-0008, 778401-0010, 778401-0011, 778401-0012, 778402-0004, 778402-0005, 778402-0006, 778402-0008, 778402-0010, 778401-0007
