Compressor wheel 813860-0001
Dimensions
- A Size A
- 44.00 mm
- A1 Size A1
- 45.60 mm
- B Size B
- 29.90 mm
- C Size C
- 3.70 mm
- C1 Size C1
- 4.00 mm
- D Size D
- 24.20 mm
- E Size E
- 4.08 mm
About product
GA-03-0017 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0017
GA-03-0017 - Alternative numbers
TCP (TurboCentras part number): GA-03-0017
TCO (TurboCentras old part number): GT14-05B
GA-03-0017 - Compatibility table
| Compressor wheel GA-03-0017 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GTD1244VZ | 813860-0001 | 813860-0001, 813860-5001S | 04L253016H |
| Garrett | GTD1244MVKZ | 813860-0002 | 813860-0002 | -- |
| Garrett | GTD1244VZ | 813860-0003 | 813860-0003, 813860-5003S | 04L253016H, 04L253016HV120 |
| Garrett | GTD1244MVZ | 824168-0002 | 824168-0002, 824168-5002S | 28201-2A820, M282012A820 |
| Garrett | GTD1244VZ | 829847-0003 | 829847-0003, 829847-5003S | 04L253016KV100 |
| Garrett | GTD1244MVZ | 829847-0005 | 829847-0005, 829847-5005S | 04L253016K |
| Garrett | GTD1244VZ | 829847-0006 | 829847-0006, 829847-5006S | 04L253016K |
| Garrett | GTD1244VZ | 847671-0002 | 847671-0002, 847671-5002S | 04L253016H |
| Garrett | GTD1244VZ | 847671-0003 | 847671-0003, 847671-5003S | 04L253020H |
| Garrett | GTD1244MVZ | 847671-0004 | 847671-0004, 847671-5004S, 847671-9004S | 04L253020S |
GA-03-0017 - Part Properties
Blades (Compressor wheel blades count): 8
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Deep Super
A (Size A): 44.00
A1 (Size A1): 45.60
B (Size B): 29.90
C (Size C): 3.70
C1 (Size C1): 4.00
D (Size D): 24.20
E (Size E): 4.08
GA-03-0017, GT14-05B
04L253016H, 813860-0001, 813860-5001S, 813860-0002, 04L253016H, 04L253016HV120, 813860-0003, 813860-5003S, 28201-2A820, 824168-0002, 824168-5002S, M282012A820, 04L253016KV100, 829847-0003, 829847-5003S, 04L253016K, 829847-0005, 829847-5005S, 04L253016K, 829847-0006, 829847-5006S, 04L253016H, 847671-0002, 847671-5002S, 04L253020H, 847671-0003, 847671-5003S, 04L253020S, 847671-0004, 847671-5004S, 847671-9004S
Specifications
Manufacturer:
SKU:
GA-03-0017
Serial number:
GA-03-0017
Main number:
GT14-05B, GA-03-0017, CW-0904B, CW-812, CW-812B
OEM number:
813860-0001, 813860-0003, 829847-0003, 847671-0002, 847671-0003, 847671-0004, 847671-0001, 829847-0005, 829847-0006, 824168-0002, 813860-0002
