Compressor wheel 789614-0001
Dimensions
- A Size A
- 38.00 mm
- A1 Size A1
- 38.00 mm
- B Size B
- 26.90 mm
- C Size C
- 3.10 mm
- C1 Size C1
- 2.40 mm
- D Size D
- 22.60 mm
- E Size E
- 4.08 mm
About product
GA-03-0007 (781909-0002) - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0007
OEM Numbers: 781909-0002
GA-03-0007 - Alternative numbers
TCP (TurboCentras part number): GA-03-0007
TCO (TurboCentras old part number): GT12-03
GA-03-0007 - Compatibility table
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
|---|---|---|---|---|
| Garrett | GT1238SZ | 789614-0001 | 789614-0001 | -- |
| Garrett | GT1238SZ | 799171-0001 | 799171-0001, 799171-5001S | 1539469, 55221180, 55231037 |
| Garrett | GT1238SZ | 799171-0002 | 799171-0002, 799171-5002S | 1819894, 55231037, DS516K682AA |
| Garrett | GT1238SZ | 799171-0004 | 799171-0004, 799171-5004S | 55491681 |
| Garrett | GT1238SZ | 809534-0001 | 809534-0001, 809534-5001S | B011372 |
| Garrett | GT1238SZ | 825246-0001 | 825246-0001, 825246-5001S | 55253504 |
| Garrett | GT1238SZ | 825246-0002 | 825246-0002, 825246-5002S | 55270402 |
GA-03-0007 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 38.00
A1 (Size A1): 38.00
B (Size B): 26.90
C (Size C): 3.10
C1 (Size C1): 2.40
D (Size D): 22.60
E (Size E): 4.08
781909-0002, GA-03-0007, GT12-03
789614-0001, 1539469, 55221180, 55231037, 799171-0001, 799171-5001S, 1819894, 55231037, 799171-0002, 799171-5002S, DS516K682AA, 55491681, 799171-0004, 799171-5004S, 809534-0001, 809534-5001S, B011372, 55253504, 825246-0001, 825246-5001S, 55270402, 825246-0002, 825246-5002S
Data updated: 2025-02-06 17:59:44
Specifications
Manufacturer:
SKU:
GA-03-0007
Serial number:
GT12-03
Main number:
781909-0002, CW-0520, 799171-0001, 799171-0002, 809534-0001, 825246-0001, 825246-0002
OEM number:
1539469, 55221180, 55231037, 1819894, DS516K682AA, B011372, 55253504, 55270402
