Compressor wheel 53049700125
Dimensions
- A Size A
- 55.00 mm
- A1 Size A1
- 55.00 mm
- B Size B
- 36.85 mm
- C Size C
- 3.85 mm
- C1 Size C1
- 2.60 mm
- D Size D
- 25.70 mm
- E Size E
- 4.61 mm
About product
BW-03-0101 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: BW-03-0101
BW-03-0101 - Alternative numbers
BWP (BorgWarner original part number): 5306 123 2025
TCP (TurboCentras part number): BW-03-0101
TCO (TurboCentras old part number): K03/04-29B
BW-03-0101 - Compatibility table
| Compressor wheel BW-03-0101 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| BorgWarner | R2S KP35 + K04 | 10009700030 | 1000 970 0030 | 03L145715B |
| BorgWarner | R2S KP35 + K04 | 10009700068 | 1000 970 0068 | 03L145701R |
| BorgWarner | R2S KP35 + K04 | 10009700096 | 1000 970 0096 | 03L145715K |
| BorgWarner | R2S KP35 + K04 | 10009700100 | 1000 970 0100 | 03L145873A |
| BorgWarner | R2S KP35 + K04 | 10009700112 | 1000 970 0112 | 03L145873D |
| BorgWarner | R2S KP35 + K04 | 10009700113 | 1000 970 0113 | 03L145715L |
| BorgWarner | K04 | 53049700125 | 5304 970 0125 | -- |
| BorgWarner | K04 | 53049700143 | 5304 970 0143 | -- |
BW-03-0101 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Super
A (Size A): 55.00
A1 (Size A1): 55.00
B (Size B): 36.85
C (Size C): 3.85
C1 (Size C1): 2.60
D (Size D): 25.70
E (Size E): 4.61
53061232025, 5306 123 2025, BW-03-0101, K03/04-29B
53049700143, 53049700125, 10009700113, 10009700112, 10009700100, 10009700096, 10009700068, 10009700030, 03L145715B, 1000 970 0030, 03L145701R, 1000 970 0068, 03L145715K, 1000 970 0096, 03L145873A, 1000 970 0100, 03L145873D, 1000 970 0112, 03L145715L, 1000 970 0113, 5304 970 0125, 5304 970 0143
Specifications
Manufacturer:
SKU:
BW-03-0101
Serial number:
BW-03-0101
Main number:
K03/04-29B, BW-03-0101, 5306 123 2025, CW-0840B
OEM number:
53049700125, 53049700143, 10009700030, 10009700068, 10009700096, 10009700100, 10009700112, 10009700113
