Compressor wheel 53039700149
Dimensions
- A Size A
- 51.00 mm
- A1 Size A1
- 53.80 mm
- B Size B
- 37.80 mm
- C Size C
- 4.00 mm
- C1 Size C1
- 1.80 mm
- D Size D
- 25.70 mm
- E Size E
- 4.61 mm
About product
BW-03-0090 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: BW-03-0090
BW-03-0090 - Alternative numbers
BWP (BorgWarner original part number): 5304 123 2043
BWP (BorgWarner original part number): 5304 123 2051
TCP (TurboCentras part number): BW-03-0090
TCO (TurboCentras old part number): K03/04-20B
BW-03-0090 - Compatibility table
| Compressor wheel BW-03-0090 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| BorgWarner | R2S K03 + B2 | 10009700135 | 1000 970 0135 | 5801733487 |
| BorgWarner | K03-2074KCA5.82KCAXM | 53039700149 | 5303 970 0149 | 55224275, 55232225 |
| BorgWarner | K03 | 53039700167 | 5303 970 0167, 5303 988 0167 | -- |
| BorgWarner | BV45-2074KCB385.18HVAXK | 53039700262 | 5303 970 0262 | 14411-5X30A |
| BorgWarner | BV45-2074KCB385.18HVAXK | 53039700338 | 5303 970 0338 | 14411-5X30B |
| BorgWarner | BV45-2074KCB385.18HVAXD | 53039700345 | 5303 970 0345 | 14411-8X00B |
| BorgWarner | BV45-2074KCB385.18HVAXK | 53039700346 | 5303 970 0346 | 14411KH80A |
| BorgWarner | BV45-2074KCB385.18HVAXD | 53039700352 | 5303 970 0352 | 14411X00C |
| BorgWarner | BV45 | 53039700712 | 5303 970 0712 | 14411-5X31A |
| BorgWarner | BV45 | 53039700713 | 5303 970 0713 | 14411-8X01B |
| BorgWarner | BV45 | 53039700737 | 5303 970 0737 | 14411-8X01D |
| BorgWarner | BV45 | 53039707035 | 5303 970 7035 | 14411-8X00D |
| BorgWarner | K04 | 53049700102 | 5304 970 0102 | -- |
| BorgWarner | K04 | 53049700105 | 5304 970 0105 | -- |
| BorgWarner | K04 | 53049700128 | 5304 970 0128 | -- |
| BorgWarner | (R2S) K04 | 53049700140 | 5304 970 0140, 5304 988 0140 | -- |
BW-03-0090 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Super
A (Size A): 51.00
A1 (Size A1): 53.80
B (Size B): 37.80
C (Size C): 4.00
C1 (Size C1): 1.80
D (Size D): 25.70
E (Size E): 4.61
53041232051, 53041232043, 5304 123 2043, 5304 123 2051, BW-03-0090, K03/04-20B
53049880140, 53049700140, 53049700128, 53049700105, 53049700102, 53039707035, 53039700737, 53039700713, 53039700712, 53039700352, 53039700346, 53039700345, 53039700338, 53039700262, 53039880167, 53039700167, 53039700149, 10009700135, 1000 970 0135, 5801733487, 5303 970 0149, 55224275, 55232225, 5303 970 0167, 5303 988 0167, 14411-5X30A, 5303 970 0262, 14411-5X30B, 5303 970 0338, 14411-8X00B, 5303 970 0345, 14411KH80A, 5303 970 0346, 14411X00C, 5303 970 0352, 14411-5X31A, 5303 970 0712, 14411-8X01B, 5303 970 0713, 14411-8X01D, 5303 970 0737, 14411-8X00D, 5303 970 7035, 5304 970 0102, 5304 970 0105, 5304 970 0128, 5304 970 0140, 5304 988 0140
Specifications
Manufacturer:
SKU:
BW-03-0090
Serial number:
BW-03-0090
Main number:
K03/04-20B, BW-03-0090, 5304 123 2043, 5304 123 2051, CW-0368-2B
OEM number:
53039700167, 53039700262, 53039700338, 53039700149, 53049700102, 53049700105, 53049700128, 53049700140, 53039700346, 53039700352, 10009700135, 53039700345, 53039700712, 53039700713, 53039700737, 53039707035
