Compressor wheel 54399700030
Dimensions
- A Size A
- 46.00 mm
- A1 Size A1
- 48.60 mm
- B Size B
- 31.00 mm
- C Size C
- 3.00 mm
- C1 Size C1
- 2.80 mm
- D Size D
- 24.80 mm
- E Size E
- 4.11 mm
About product
BW-03-0058 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: BW-03-0058
BW-03-0058 - Alternative numbers
BWP (BorgWarner original part number): 5443 123 2017
BWP (BorgWarner original part number): 5443 123 2037
BWP (BorgWarner original part number): 5443 1232037
TCP (TurboCentras part number): BW-03-0058
TCO (TurboCentras old part number): KP39-07
BW-03-0058 - Compatibility table
| Compressor wheel BW-03-0058 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| BorgWarner | BV39-1867DCG426.18AVAXH | 54399700030 | 5439 970 0030 | 8200405203, 8200507856, 8200578381 |
| BorgWarner | BV39-1867DCG426.18AVAXH | 54399700046 | 5439 970 0046 | 8200678809 |
| BorgWarner | BV39-1867DCG426.18AVAXH | 54399700066 | 5439 970 0066 | 8200552213, 8200588232 |
| BorgWarner | BV39-1867DCG426.18AVAXC | 54399700070 | 5439 970 0070 | 8200625683 |
| BorgWarner | BV39-1867DBG340.18AVBXK | 54399700076 | 5439 970 0076 | 144114256R, 8200808701 |
| BorgWarner | BV39-1867DCG426.18AVAXH | 54399700080 | 5439 970 0080, 5439 998 0080 | 8200846770 |
| BorgWarner | BV39-1867DBG340.18AVBXC | 54399700087 | 5439 970 0087 | 8200889697 |
| BorgWarner | BV39-1867DCG426.18AVAXC | 54399700090 | 5439 970 0090, 5439 998 0090 | 8200905276 |
| BorgWarner | BV39-1867DBG340.18AVBXC | 54399700127 | 5439 970 0127, 5439 971 0127, 5439 998 0127 | 144115524R, 144116289R |
BW-03-0058 - Part Properties
Blades (Compressor wheel blades count): 5/5
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 46.00
A1 (Size A1): 48.60
B (Size B): 31.00
C (Size C): 3.00
C1 (Size C1): 2.80
D (Size D): 24.80
E (Size E): 4.11
54431232037, 54431232037, 54431232017, 5443 123 2017, 5443 123 2037, 5443 1232037, BW-03-0058, KP39-07
54399980127, 54399710127, 54399700127, 54399980090, 54399700090, 54399700087, 54399980080, 54399700080, 54399700076, 54399700070, 54399700066, 54399700046, 54399700030, 5439 970 0030, 8200405203, 8200507856, 8200578381, 5439 970 0046, 8200678809, 5439 970 0066, 8200552213, 8200588232, 5439 970 0070, 8200625683, 144114256R, 5439 970 0076, 8200808701, 5439 970 0080, 5439 998 0080, 8200846770, 5439 970 0087, 8200889697, 5439 970 0090, 5439 998 0090, 8200905276, 144115524R, 144116289R, 5439 970 0127, 5439 971 0127, 5439 998 0127
Specifications
Manufacturer:
SKU:
BW-03-0058
Serial number:
BW-03-0058
Main number:
KP39-07, 5443 123 2037, BW-03-0058, 5443 123 2017, CW-0412
OEM number:
54399700076, 54399700087, 54399980127, 54399700030, 54399700070, 54399700066, 54399700080, 54399700046, 54399700090
