Compressor wheel 54359700039
Dimensions
- A Size A
- 41.10 mm
- A1 Size A1
- 42.50 mm
- B Size B
- 30.80 mm
- C Size C
- 3.55 mm
- C1 Size C1
- 2.80 mm
- D Size D
- 23.70 mm
- E Size E
- 4.11 mm
About product
BW-03-0047 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: BW-03-0047
BW-03-0047 - Alternative numbers
BWP (BorgWarner original part number): 5439 123 2022
TCP (TurboCentras part number): BW-03-0047
TCO (TurboCentras old part number): KP35-09B
BW-03-0047 - Compatibility table
| Compressor wheel BW-03-0047 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| BorgWarner | B01V | 16389500002 | 1638 950 0002 | 28201-2A790 |
| BorgWarner | B01V | 16389500009 | 1638 950 0009 | 28201-2A790 |
| BorgWarner | B01V | 16389700014 | 1638 970 0014, 1638 988 0014 | 28201-2A780, 28500-2A780 |
| BorgWarner | BV35 | 54359700039 | 5435 970 0039 | 7812318 |
| BorgWarner | BV35 | 54359700040 | 5435 970 0040 | 8514666 |
| BorgWarner | BV35 | 54359700041 | 5435 970 0041 | 7812318 |
| BorgWarner | BV35 | 54359700047 | 5435 970 0047 | 7812318 |
| BorgWarner | BV35 | 54359700055 | 5435 970 0055 | 3465483 |
| BorgWarner | BV35 | 54359700056 | 5435 970 0056 | 8573105 |
| BorgWarner | BV35 | 54359700066 | 5435 970 0066, 5435 988 0066 | 3465485 |
| BorgWarner | BV35 | 54359880048 | 5435 970 0048, 5435 971 0048, 5435 988 0048 | 8514666, 8514667 |
BW-03-0047 - Part Properties
Blades (Compressor wheel blades count): 5/5
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Super
A (Size A): 41.10
A1 (Size A1): 42.50
B (Size B): 30.80
C (Size C): 3.55
C1 (Size C1): 2.80
D (Size D): 23.70
E (Size E): 4.11
54391232022, 5439 123 2022, BW-03-0047, KP35-09B
54359880048, 54359710048, 54359700048, 54359880066, 54359700066, 54359700056, 54359700055, 54359700047, 54359700041, 54359700040, 54359700039, 16389880014, 16389700014, 16389500009, 16389500002, 1638 950 0002, 28201-2A790, 1638 950 0009, 28201-2A790, 1638 970 0014, 1638 988 0014, 28201-2A780, 28500-2A780, 5435 970 0039, 7812318, 5435 970 0040, 8514666, 5435 970 0041, 7812318, 5435 970 0047, 7812318, 3465483, 5435 970 0055, 5435 970 0056, 8573105, 3465485, 5435 970 0066, 5435 988 0066, 5435 970 0048, 5435 971 0048, 5435 988 0048, 8514666, 8514667
Specifications
Manufacturer:
SKU:
BW-03-0047
Serial number:
BW-03-0047
Main number:
KP35-09B, BW-03-0047, 5439 123 2022, CW-1172B
OEM number:
54359700039, 54359700040, 54359700041, 54359700047, 54359700056, 54359700055, 54359700066, 16389700014, 54359880048, 16389500002, 16389500009
