Compressor wheel CNC 53039700324
Dimensions
- A Size A
- 49.00 mm
- A1 Size A1
- 50.50 mm
- B Size B
- 38.30 mm
- C Size C
- 4.30 mm
- C1 Size C1
- 3.30 mm
- D Size D
- 27.80 mm
- E Size E
- 4.61 mm
About product
BW-03-0010 - Compressor wheel
Brand: TurboCentras
BW-03-0010 - Alternative numbers
TCO (TurboCentras old part number): BV43-03B
TCP (TurboCentras part number): BW-03-0010
BW-03-0010 - Compatibility table
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
|---|---|---|---|---|
| BorgWarner | BV43 | 53039700324 | 5303 970 0324 | 04L253010L |
| BorgWarner | BV43 | 53039700359 | 5303 970 0359 | 04L253010N |
| BorgWarner | BV43 | 53039700385 | 5303 970 0385 | 04L253010S |
| BorgWarner | BV43 | 53039700414 | 5303 970 0414 | 04L253056C |
| BorgWarner | BV43 | 53039700433 | 5303 970 0433 | 04L253010A |
| BorgWarner | BV43 | 53039700441 | 5303 970 0441 | 04L253056E |
| BorgWarner | BV43 | 53039700443 | 5303 970 0443 | 04L253056G |
| BorgWarner | BV43 | 53039700475 | 5303 970 0475 | 04L253056F |
| BorgWarner | BV43 | 53039700476 | 5303 970 0476 | 04L253056H |
| BorgWarner | BV43 | 53039700476-R | 5303 970 0476 | 04L253056H |
| BorgWarner | BV43 | 53039700477 | 5303 970 0477 | 04L253056G |
| BorgWarner | BV43 | 53039700478 | 5303 970 0478 | 04L253056J |
| BorgWarner | BV43 | 53039700542 | 5303 970 0542 | 04L253056L |
| BorgWarner | BV43 | 53039700543 | 5303 970 0543 | 04L253056M |
| BorgWarner | BV43 | 53039700620 | 5303 970 0620, 5303 988 0620 | 04L253124 |
| BorgWarner | BV43 | 53039700621 | 5303 970 0621, 5303 988 0621 | 04L253124A |
BW-03-0010 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Deep Super
A (Size A): 49.00
A1 (Size A1): 50.50
B (Size B): 38.30
C (Size C): 4.30
C1 (Size C1): 3.30
D (Size D): 27.80
E (Size E): 4.61
5304-123-2334, 5304-123-2339, 5304-123-2340, 5304-123-2348, 5304-123-2349, BV43-03B, BW-03-0010
53039880621, 53039700621, 53039880620, 53039700620, 53039700543, 53039700542, 53039700478, 53039700477, 53039700476, 53039700476, 53039700475, 53039700443, 53039700441, 53039700433, 53039700414, 53039700385, 53039700359, 53039700324, 04L253010L, 5303 970 0324, 04L253010N, 5303 970 0359, 04L253010S, 5303 970 0385, 04L253056C, 5303 970 0414, 04L253010A, 5303 970 0433, 04L253056E, 5303 970 0441, 04L253056G, 5303 970 0443, 04L253056F, 5303 970 0475, 04L253056H, 5303 970 0476, 04L253056H, 5303 970 0476, 04L253056G, 5303 970 0477, 04L253056J, 5303 970 0478, 04L253056L, 5303 970 0542, 04L253056M, 5303 970 0543, 04L253124, 5303 970 0620, 5303 988 0620, 04L253124A, 5303 970 0621, 5303 988 0621
Data updated: 2025-02-04 17:03:05
Specifications
Manufacturer:
SKU:
BW-03-0010
Serial number:
BW-03-0010
Main number:
BW-03-0010, BV43-03B, 5304 123 2334, 5304 123 2339, 5304 123 2340, 5304 123 2348, 5304 123 2349, CW-1319B
OEM number:
53039700324, 53039700359, 53039700385, 53039700414, 53039700441, 53039700475, 53039700476, 53039700542, 53039700620, 53039700478, 53039700543, 53039700621, 53039700443, 53039700477
