Hybrid turbine core 06K145702J IS38 VW Golf VII 2.0L TSI 206kW 2013.

Introducing our new product—a modified core for the IS38 Hybrid Turbocharger! Our new part features converted ball bearings, a larger compressor wheel, and a turbine shaft, delivering unmatched performance and flexibility.

The biggest advantage of ball bearings is minimal rolling friction, which means that our turbocharger spools up much faster than traditional models with sleeve bearings. This is also confirmed by graphs illustrating the performance of turbochargers with different types of bearings. Compressor wheel dimensions: - Dimension A: 49 mm - Dimension B: 64 mm - Dimension C: 67,8 mm Turbine shaft dimensions: - Dimension A: 47 mm - Dimension B: 54 mm

Our turbocharger core allows you to achieve maximum performance, requiring only appropriate modifications to the intake, fuel, and exhaust systems, resulting in an impressive power output of 520KM/388 kW.

Our IHI® turbochargers are factory-installed in a wide range of vehicles, including:

• Audi A3 CJXC 2.0L 300KM/220kW 2012/11 - 2019/12
• Audi S3 quattro Sportback Limousine CJXC 2.0L 280KM/206kW 2013/02 - 2019/12
• Audi S3 Sportback CJXF 2.0L 286KM/210kW 2014/05 - 2019/12
• Audi S3 Cabriloet quattro CJXF 2.0L 310KM/228kW 06.2016 - 12.2019
• Audi S3 quattro Sportback Limousine Cabriolet CJXC 2.0L 290KM/213kW 07.2016 - 12.2019
• Audi S3 quattro Cabriolet Limousine CJXA 2.0L 286KM/210kW 03.2014 - 12.2019
• Audi S3 quattro Cabriolet Sportback Limousine CJXA 2.0L 300KM/220kW 04.2014 - 12.2019
• Audi A3 Limousine Sportback 8VS 8VM S3 quattro CJXC 2.0L 310KM/228kW 06.2016 - 12.2019
• Audi TT 2.0 TTS quattro Roadster CJXF 2.0L 310KM/228kW 2014/11 - 2019/12
• Audi TT 2.0 TTS quattro Roadster CJXC 2.0L 286KM/210kW 2014/11 - 2019/12
• Seat Leon ST/SC 2.0 Cupra 5F8 5F5 CJXB 2.0L 265KM/195kW 10.2013 - 12.2016
• Seat Leon ST/SC 2.0 Cupra / Kombi CJXB 2.0L 280KM/206kW 10.2013 - 12.2016
• Seat Leon ST/SC 2.0 Cupra 5F8 5F5 CJXB 2.0L 290KM/213kW 10.2015 - 12.2019
• Seat Leon ST/SC 2.0 Cupra Kombi 5F8 5F5 CJXB 2.0L 300KM/220kW 01.2017 - 12.2019
• Seat Leon 2.0 Cupra R CJXB 2.0L 310KM/228kW 11.2017 - 12.2019
• Skoda Superb III 2.0 TSI 4x4 / Kombi CJXA 2.0L 280KM/206kW 03.2015 - 12.2019
• Skoda Superb III 2.0 TSI 4x4 / Kombi CJXA 2.0L 272KM/200kW 03.2015 - 12.2019
• VW Golf VII 2.0 R 4motion / BA5 Variant CJXB 2.0L 280KM/206kW 11.2013 - 12.2019
• VW Golf VII 5G1 2.0 R 4motion / BA5 Variant CJXC 2.0L 300KM/220kW 11.2013 - 12.2019
• VW Golf VII 5G1 BE1 2.0 GTI Clubsport CJXF 2.0L265KM/195kW 02.2016 - 12.2019
• VW Golf VII 5G1 BE1 BV5 BE2 2.0 GTI Clubsport S Variant CJXC 2.0L 310 KM 09.2016 - 12.2019
• VW Golf VII BA5 BV5 5G1 BQ1 BE1 2.0 GTI Variant CJXF 2.0L 290KM/213kW 2019/01 - 2019/12
• VW Passat 3G5 3G2 2.0 TSI 4motion Variant CJXF 2.0L 280KM/206kW 05.2015 - 12.2019
• VW Passat 3G5 3G2 2.0 TSI 4motion Variant CJXF 2.0L272KM/200kW 09.2018 - 12.2019
• VW Scirocco 2014/05-2017/11 137 138 2.0 R 2.0L 280KM/206kW 05.2014 - 11.2017

Our turbocharger replaces the original models with the following part numbers:

• IS38
• 06K145874N
• 06K145874F
• 06K145722T
• 06K145722P
• 06K145722H
• 06K145722A
• 06K145702N
• 06K145702M
• 06K145702J
• 06K145702H
• 9VA04
• 06K145874P
• 06K145874G
• 06K145722S
• 06K145722N
• 9VA05
