Wałek turbiny do 9VB03

Wymiary Wałka turbiny:

Blades (Shaft & Wheel blades count): 9

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Slender

Back (Shaft & Wheel back type): Full

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 38.95

A1 (Size A1): 38.95

B (Size B): 35.50

C (Size C): 7.38

D (Size D): 7.40

E (Size E): 5.10

H (Size H): 20.00

L (Size L): 95.00

T (Size T): M.5.0X0.5LH

Wałek turbiny pasuję do następujących turbosprężarek:

• 9VB03 9V102 AL-0058 V41VEY-SR025B 9VB01 V41VEG-SR022B 9VB02 V41VEG-SR066B
• 11658573107 8573107 8573107-03 8573107.03 11658573108 8573108 8573108-03 8573108.03 A6510900886 A6510901780 A6510903400 11657812321 1165781232102 1165781232103 11658506722 11658513122 1165851312202 11658513123 11658513124 11658518204 1165851820401 1165851820402 11658518205 1165851820502 7812321 7812321.03 781232102 781232103 8506722 8513122 8513123 8513124 8518204 8518204.02 851820402 8518205 8518205.02 851820502 11658512379 1165851237902 1165851237903 1165851237907 11658512454 8512379.02 8512379.03 8512379.04 8512379.05 8512379.07 851237902 851237903 851237907 8512454
