Koło kompresji 436563-0001

GA-03-0080 - Koło kompresji

Marka: TurboCentras

TurboCentras Reference: GA-03-0080

GA-03-0080 - Alternative numbers

GHP (Garrett original part number): 436563-0001

GHP (Garrett original part number): 436563-0009

GHP (Garrett original part number): 703361-0010

TCP (TurboCentras part number): GA-03-0080

TCO (TurboCentras old part number): GT22-00

GA-03-0080 - Compatibility table

GA-03-0080 - Part Properties

Blades (Compressor wheel blades count): 6/6

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Cast

Back (Compressor wheel back design): Deep Super

A (Size A): 56.00

A1 (Size A1): 56.00

B (Size B): 41.60

C (Size C): 4.55

C1 (Size C1): 3.75

D (Size D): 30.80

E (Size E): 5.08

436563-0001, 436563-0009, 703361-0010, GA-03-0080, GT22-00

11657785992, 11657785993, 700935-0001, 700935-5001S, 7785991B, 700935-0002, 700935-0003, 700935-5003S, 7785993B, 11657785992, 11657785993, 700935-0004, 700935-5004S, 7785991C03, 700935-0006, 700935-5006S, 7785993C03, 700935-0007, 700935-5007S, 700935-9007W, 7785993C03, 2249950.9, 704361-0001, 11652249950, 11652249951, 11657785989, 11657785990, 11657786070, 11657786071, 2248834E, 704361-0004, 704361-5004S, 11652249950, 11652249951, 11657785989, 11657785990, 11657786070, 11657786071, 22499519, 704361-0005, 704361-5005S, 22499509, 704361-0006, 704361-5006S, 22499509, 704361-0010, 704361-5010S, 704361-9010S, 612096049980, 711009-0001, 711009-5001S, A6120960499, 612096049980, 711009-0002, 711009-5002S, A6120960499, 612096049980, 711009-0003, 711009-5003S, 711009-9003S, A6120960499, 712541-0001, 7785838F, 712541-0002, 7785839F, 712541-0003, 7785840F, 712541-0004, 7785838G04, 712541-0005, 7785839G04, LR018264, LR06705, 712541-0006, 7785840G04, 712541-0007, 7785839G04, LR018264, LR06705, 715568-0001, 715568-0002, 715568-0003, 721204-0001, 727463-0001, 727463-5001S, A6470960099, 727463-0002, 727463-5002S, A6470960099, 727463-0003, 727463-5003S, A6470960099, 727463-0004, 727463-5004S, A6470900180, 727463-0006, 727463-5006S, 727463-9006S, A6470900180, 732610-0009, 1118300SD, 736210-0003, 736210-5003S, 1118300SZ, 736210-0005, 736210-5005S, 1118300TAR, 736210-0006, 736210-5006S, 1118300SBJMTL, 736210-0007, 736210-5007S, 1118300DL, 736210-0009, 736210-5009S, 1118300AAD, 736210-0010, 736210-5010S, 738769-0001, 738769-5001S, E049339000082, 738769-0002, 738769-5002S, E049339000096, 738769-0004, 738769-5004S, E049339000054, 738769-0009, 738769-5009S, E049339000167, 738769-0010, 738769-5010S, E049339000186, 738769-0014, 14411-7T600, 741157-0001, 741157-5001S, 742289-0001, 742289-0002, 742289-0003, 742289-0004, 742289-0005, 504084355, 750510-0001, 750510-5001S, 504071574, 751578-0001, 751578-5001S, 504071573, 751578-0002, 751578-5001S, 500379251, 751758-0001, 751758-5001S, 751758-9001S, 500379251, 751758-0002, 751758-5002S, 751758-9002S, 752528-0005, 752528-5005S, 905292010097, 1008200FA060, 759638-0002, 759638-5002S, 1008200FA011, 759638-0004, 759638-5004S, 252714510129, 762803-0001, 762803-5001S, 252714510127, 762803-0002, 762803-5002S, 3819920, 763263-0002, 763263-5002S, 3847393, 763263-0003, 763263-5003S, 763263-0004, 763263-0006, 763263-5006S, 765326-0002, 765326-5002S, 9.0529.201.0091, 90529201012102, 4102C3C1010, 785305-0001, 785305-5001S, 4102C3C1010A, 785305-0002, 785305-5002S, 4102C3C1010B, 785305-0003, 785305-5003S, 4102C3C1010C1, 785305-0004, 785305-5004S, 4102C3D1010, 785305-0005, 785305-5005S, 4102C3D1010A, 785305-0006, 785305-5006S, 4102C3D1010B, 785305-0007, 785305-5007S, 4102C3D1010C, 785305-0008, 785305-5008S, 4102C3F1010, 785305-0013, 785305-5013S, 4102C3F1010A, 785305-0014, 785305-5014S, 4102C3F10101, 785305-0015, 785305-5015S, 4102C3F1010C1, 785305-0016, 785305-5016S
