Wałek turbiny do KHF5-2B

Wymiary Wałka turbiny:

Blades (Shaft & Wheel blades count): 8

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Open

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 44.40

A1 (Size A1): 36.00

B (Size B): 37.60

C (Size C): 5.00

D (Size D): 8.00

E (Size E): 5.10

F (Size F): 45.20

G (Size G): 40.20

H (Size H): 19.00

L (Size L): 99.00

T (Size T): M5.0X0.5 LH

Wałek turbiny pasuję do następujących turbosprężarek:

• KHF5-2B RHF5-2B F51CAD-S0023B VA430023 VB430023 VD430023 VE430023 VICC VA430024 VD430024 VE430024 VICD VICF F51CAD-S0027B F51CAD-S0027G VA430027 VB430027 VC430027 VE430027 VF430027 VG430027 VH430027 VI430027 VICI VJ430027 VK430027 VL430027 VM430027 VA430057 VB430057 VC430057 VICX VA430056 VC430056 VD430056 VF430056 VH430056 VIDH VA430070 VB430070 VIDS F51CAD-S0077B F51CAD-S0077G V*430077 VA430077 VB430077 VC430077 VIDW F51CAD-S0084B F51CAD-S0093B VC430084 VIED VA430086 VB430086 VIEG F51CAD-S0093B VB430093 VIEK F51CAD-S0132B F51CAD-S0132G VA430132 VB430132 VIFR F51CAD-S0144B F51CAD-S0144G VIFV VR14 KHF5-1A VA430036 VB430036 VR12A VR15 KHF5-4A VR18
• 28200-4X400 28201-4X700 28201-4X701 28201-4X710 8970385180 8970385181 8971673342 860065 8971371098 8971371099 8972503640 8972503641 8972503642 897376273 97376273 98102371 8971371911 8971371912 8971371913 8971371915 8971371916 8971371917 8972553220 8972553221 8972553222 8972553223 8972263381 8972400082 8972400083 8973109482 8973109483 8973659480 8973659481 8973659482 8979431960 8979431961 8973544234 8980151151 8980151152 8980540111 28200-4X300 OK059A-13700 OK551-13700C 28200-4X610 28201-4X610
