Wałek turbiny do 10009700153 BW-02-0007

BW-02-0007 - Part Properties

Blades (Shaft & Wheel blades count): 7

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Full

P.R. (Shaft & Wheel piston rings count): Twin

A (Size A): 35.10

A1 (Size A1): 35.10

B (Size B): 30.55

C (Size C): 5.20

D (Size D): 6.00

E (Size E): 4.00

F (Size F): 43.60

G (Size G): 29.60

H (Size H): 15.00

L (Size L): 83.00

T (Size T): M4.0X0.5LH

• 16359880040, 16359700056, 16359880040, 16359700040, 16359700024, 16359700022, 16359700018, 10009700206, 10009700205, 16359700016, 10009700191, 16359700012, 16359700002, 10009710384, 10009710383, 10009710381, 10009710377, 10009710376, 10009710359, 10009700385, 10009700384, 10009700383, 10009700382, 10009700381, 10009700378, 10009700377, 10009700376, 10009700359, 10009700358, 10009700313, 10009700286, 10009700277, 10009700273, 10009700238, 10009700234, 10009700227, 10009700225, 10009700153
• 03N145703C, 1000 970 0153, 03N145701Q, 1000 970 0225, 03N145701G, 1000 970 0227, 03N145701K, 1000 970 0234, 03N145701R, 1000 970 0238, 03N145701M, 1000 970 0273, 03N145701R, 1000 970 0277, 03N145701L, 1000 970 0286, 03N145702, 1000 970 0313, 03N145702A, 1000 970 0358, 03N145701T, 1000 970 0359, 03N145702L, 1000 970 0376, 03N145702N, 1000 970 0377, 03N145702J, 1000 970 0378, 03N145702S, 1000 970 0381, 03N145702T, 1000 970 0382, 03N145704M, 1000 970 0383, 03N145704N, 1000 970 0384, 03N145704P, 1000 970 0385, 03N145703T, 1000 971 0359, 03N145704C, 1000 971 0376, 03N145704, 1000 971 0377, 03N145704E, 1000 971 0381, 03N145704L, 1000 971 0383, 03N145704K, 1000 971 0384, 04L253016F, 1635 970 0002, 04L253016T, 1635 970 0012, 1000 970 0191, 1635 970 0016, 1000 970 0205, 1000 970 0206, 1635 970 0018, 1635 970 0022, 1635 970 0024, 04L253020R, 1635 970 0040, 1635 988 0040, 1635 970 0056, 04L253020R, 1635 988 0040

Data updated: 2025-02-14 16:51:17
