Compressor wheel 786266-0001

GA-03-0068 - Koło kompresji

Marka: TurboCentras

TurboCentras Reference: GA-03-0068

GA-03-0068 - Alternative numbers

GHP (Garrett original part number): 788529-0002

TCP (TurboCentras part number): GA-03-0068

TCO (TurboCentras old part number): GT17-12

GA-03-0068 - Compatibility table

Compressor wheel GA-03-0068 - Compatible turbochargers
TURBO MAKER	TURBO MODEL	TURBO REFERENCE	TURBO PART NUMBER	TURBO OE NUMBER
Garrett	GTB1749VZK	786266-0005	786266-0005	057145874M
Garrett	GTB1749VZ	786267-0005	786267-0005	--
Garrett	GTB1749VZK	797517-0002	797517-0002	057145874N
Garrett	GTB1749VZK	797517-0003	797517-0003	057145874M
Garrett	GTB1749VK	797517-0004	797517-0004	--
Garrett	GTB1749VZ	797518-0002	797518-0002, 797518-2, 797518-5002S, 797518-9004S	057145873N
Garrett	GTB1749VZ	797518-0003	797518-0003, 797518-3, 797518-5003S, 797518-9004S	057145873N

GA-03-0068 - Part Properties

Blades (Compressor wheel blades count): 9

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Cast

Back (Compressor wheel back design): Deep Super

A (Size A): 49.00

A1 (Size A1): 49.00

B (Size B): 36.40

C (Size C): 4.35

C1 (Size C1): 4.00

D (Size D): 26.40

E (Size E): 5.08

---
