Koło kompresji CNC tytanowe 813860-0001

GA-03-0018 - Koło kompresji

Marka: TurboCentras

TurboCentras Reference: GA-03-0018

GA-03-0018 - Alternative numbers

TCP (TurboCentras part number): GA-03-0018

TCO (TurboCentras old part number): GT14-05T

GA-03-0018 - Compatibility table

Compressor wheel GA-03-0018 - Compatible turbochargers
TURBO MAKER	TURBO MODEL	TURBO REFERENCE	TURBO PART NUMBER	TURBO OE NUMBER
Garrett	GTD1244VZ	813860-0001	813860-0001, 813860-5001S	04L253016H
Garrett	GTD1244MVKZ	813860-0002	813860-0002	--
Garrett	GTD1244VZ	813860-0003	813860-0003, 813860-5003S	04L253016H, 04L253016HV120
Garrett	GTD1244MVZ	824168-0002	824168-0002, 824168-5002S	28201-2A820, M282012A820
Garrett	GTD1244VZ	829847-0003	829847-0003, 829847-5003S	04L253016KV100
Garrett	GTD1244MVZ	829847-0005	829847-0005, 829847-5005S	04L253016K
Garrett	GTD1244VZ	829847-0006	829847-0006, 829847-5006S	04L253016K
Garrett	GTD1244VZ	847671-0002	847671-0002, 847671-5002S	04L253016H
Garrett	GTD1244VZ	847671-0003	847671-0003, 847671-5003S	04L253020H
Garrett	GTD1244MVZ	847671-0004	847671-0004, 847671-5004S, 847671-9004S	04L253020S

GA-03-0018 - Part Properties

Blades (Compressor wheel blades count): 8

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Billet Titan

Back (Compressor wheel back design): Super

A (Size A): 44.00

A1 (Size A1): 45.60

B (Size B): 29.90

C (Size C): 3.70

C1 (Size C1): 4.00

D (Size D): 24.20

E (Size E): 4.08





---



GA-03-0018, GT14-05T

---

04L253016H, 813860-0001, 813860-5001S, 813860-0002, 04L253016H, 04L253016HV120, 813860-0003, 813860-5003S, 28201-2A820, 824168-0002, 824168-5002S, M282012A820, 04L253016KV100, 829847-0003, 829847-5003S, 04L253016K, 829847-0005, 829847-5005S, 04L253016K, 829847-0006, 829847-5006S, 04L253016H, 847671-0002, 847671-5002S, 04L253020H, 847671-0003, 847671-5003S, 04L253020S, 847671-0004, 847671-5004S, 847671-9004S

---
