Koło kompresji 167432

BW-03-0143 - Koło kompresji

Marka: TurboCentras

TurboCentras Reference: BW-03-0143

BW-03-0143 - Alternative numbers

BWP (BorgWarner original part number): 167731

TCP (TurboCentras part number): BW-03-0143

TCO (TurboCentras old part number): S200-01

BW-03-0143 - Compatibility table

Compressor wheel BW-03-0143 - Compatible turbochargers
TURBO MAKER	TURBO MODEL	TURBO REFERENCE	TURBO PART NUMBER	TURBO OE NUMBER
BorgWarner	S200S001	167432	167432	0R6477, 118-2024
BorgWarner	S200S001	168413	168413	126-5417
BorgWarner	S200S001	168414	168414	126-5418
BorgWarner	S200S001	168415	168415	126-5419
BorgWarner	S200G001	168464	168464	0R7056, 127-6441
BorgWarner	S200S001	168475	168475	127-9330
BorgWarner	S200G001	168867	168867	0R7099, 133-3830
BorgWarner	S200	168870	168870	0R7100, 133-5324
BorgWarner	S200G001	168878	168878	133-2305
BorgWarner	S200S022	169596	169596	0R7224, 147-7265
BorgWarner	S200S022	169598	169598	145-6096
BorgWarner	S200G022	169617	169617	147-9532
BorgWarner	S200S022	169678	169678	148-5701
BorgWarner	S200	169679	169679	--
BorgWarner	S200	169680	169680	--
BorgWarner	S200	169682	169682	--
BorgWarner	S200	169683	169683	--
BorgWarner	S200	169685	169685	--
BorgWarner	S200	169686	169686	--
BorgWarner	S200S022	170071	170071	159-4738
BorgWarner	S200G022	170072	170072	159-4740
BorgWarner	S200S022	170215	170215	162-9101
BorgWarner	S200	171532	171532	0R7099, 190-3944
BorgWarner	S200G001	178077	167434, 168476, 168698, 169264, 169294, 169374, 169592, 178077	0R6942, 118-2026, 127-9331, 130-7283, 137-9834, 138-2104, 139-8466, 145-6093
BorgWarner	S200G001	178078	167435, 168416, 168477, 168909, 169449, 169593, 169820, 178078	0R6943, 118-2027, 126-5420, 127-9332, 133-9238, 141-9231, 145-6094, 151-5262
BorgWarner	S200G046	178089	169613, 169616, 169676, 171744, 171745, 171746, 171747, 171748, 171749, 171750, 171751, 171752, 178089, 478089, 478089	0R7225, 0R9865, 146-1623, 147-7264, 148-5702, 186-2532, 195-5992, 195-5993, 195-5994, 195-5995, 195-5996, 195-5997, 195-5998, 195-5999
BorgWarner	S200S044	178470	169604, 171717, 171718, 171719, 171720, 171721, 171722, 171723, 171724, 171725, 171726, 178470	0R7586, 147-9534, 186-2528, 195-6013, 195-6015, 195-6016, 195-6018, 195-6019, 195-6020, 195-6021, 195-6022, 195-6023
BorgWarner	S200S001	179580	167433, 179580	0R6478, 118-2025

BW-03-0143 - Part Properties

Blades (Compressor wheel blades count): 7/7

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Cast

Back (Compressor wheel back design): Super

A (Size A): 79.80

A1 (Size A1): 79.80

B (Size B): 58.50

C (Size C): 6.65

C1 (Size C1): 6.40

D (Size D): 46.60

E (Size E): 7.00

---
