Koło kompresji 53049700086
Wymiary
- A Size A
- 56.00 mm
- A1 Size A1
- 58.00 mm
- B Size B
- 39.30 mm
- C Size C
- 4.15 mm
- C1 Size C1
- 1.80 mm
- D Size D
- 25.70 mm
- E Size E
- 4.61 mm
O produkcie
BW-03-0089 - Koło kompresji
Marka: TurboCentras
TurboCentras Reference: BW-03-0089
BW-03-0089 - Alternative numbers
BWP (BorgWarner original part number): 5306 123 2016
TCP (TurboCentras part number): BW-03-0089
TCO (TurboCentras old part number): K03/04-19B
BW-03-0089 - Compatibility table
| Compressor wheel BW-03-0089 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| BorgWarner | R2S KP35 + K04 | 10009500026 | 1000 950 0026 | 55562590 |
| BorgWarner | R2S KP35 + K04 | 10009700005 | 1000 970 0005 | 55215256, 93166899, 93194991 |
| BorgWarner | R2S KP39 + K04 | 10009700008 | 1000 970 0008 | 6510900880, 6510902280, 6510904780, 6510904880, 6510905280 |
| BorgWarner | R2S KP35 + K04 | 10009700018 | 1000 970 0018 | 55579038 |
| BorgWarner | R2S KP35 + K04 | 10009700027 | 1000 970 0027 | 03L145715 |
| BorgWarner | R2S KP39 + K04 | 10009700036 | 1000 970 0036 | 6510906080 |
| BorgWarner | R2S KP39 + K04 | 10009700037 | 1000 970 0037, 1000 988 0037 | 6510905480 |
| BorgWarner | R2S KP35 + K04 | 10009700053 | 1000 970 0053 | 03L145701G |
| BorgWarner | R2S KP35 + K04 | 10009700062 | 1000 970 0062 | 55577924 |
| BorgWarner | R2S KP35 + K04 | 10009700064 | 1000 970 0064, 1000 988 0064 | 03L145715D |
| BorgWarner | R2S KP35 + K04 | 10009700067 | 1000 970 0067 | 03L145701G |
| BorgWarner | R2S KP39 + K04 | 10009700074 | 1000 970 0074, 1000 988 0074, 1000 990 0074 | 6510906380, A 651 090 63 80 |
| BorgWarner | R2S KP35 + K04 | 10009700098 | 1000 970 0098, 1000 988 0098, 1000 993 0098 | 03L145715J |
| BorgWarner | R2S KP35 + K04 | 10009700099 | 1000 970 0099 | 03L145873 |
| BorgWarner | K04-2270DGB5.82GCAAK | 53049700086 | 5304 970 0086 | 6510900980 |
| BorgWarner | K04 | 53049700103 | 5304 970 0103 | -- |
| BorgWarner | R2S KP39 + K04 | 53049700127 | 5304 970 0127 | 6510905680 |
| BorgWarner | K04 | 53049700129 | 5304 970 0129 | -- |
| BorgWarner | K04 | 53049700139 | 5304 970 0139 | -- |
BW-03-0089 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Super
A (Size A): 56.00
A1 (Size A1): 58.00
B (Size B): 39.30
C (Size C): 4.15
C1 (Size C1): 1.80
D (Size D): 25.70
E (Size E): 4.61
53061232016, 5306 123 2016, BW-03-0089, K03/04-19B
53049700139, 53049700129, 53049700127, 53049700103, 53049700086, 10009700099, 10009930098, 10009880098, 10009700098, A6510906380, 10009900074, 10009880074, 10009700074, 10009700067, 10009880064, 10009700064, 10009700062, 10009700053, 10009880037, 10009700037, 10009700036, 10009700027, 10009700018, 10009700008, 10009700005, 10009500026, 1000 950 0026, 55562590, 1000 970 0005, 55215256, 93166899, 93194991, 1000 970 0008, 6510900880, 6510902280, 6510904780, 6510904880, 6510905280, 1000 970 0018, 55579038, 03L145715, 1000 970 0027, 1000 970 0036, 6510906080, 1000 970 0037, 1000 988 0037, 6510905480, 03L145701G, 1000 970 0053, 1000 970 0062, 55577924, 03L145715D, 1000 970 0064, 1000 988 0064, 03L145701G, 1000 970 0067, 1000 970 0074, 1000 988 0074, 1000 990 0074, 6510906380, A 651 090 63 80, 03L145715J, 1000 970 0098, 1000 988 0098, 1000 993 0098, 03L145873, 1000 970 0099, 5304 970 0086, 6510900980, 5304 970 0103, 5304 970 0127, 6510905680, 5304 970 0129, 5304 970 0139
Specyfikacja
Producent
SKU
BW-03-0089
Stan
Nowy
Główny numer
K03/04-19B, BW-03-0089, 5306 123 2016, CW-0773B
Numer OEM
10009700074, 10009700027, 10009700053, 10009700064, 10009700067, 10009700098, 10009700099, 53049700103, 53049700129, 53049700139, 53049700086, 10009700005, 10009700008, 10009700018, 10009700036, 10009700062, 10009500026, 53049700127, 10009700037
Gwarancja
12 miesięcy gwarancji producenta
Dostawa i płatność
Komponenty
33 części
