Koło kompresji 54389700000
Wymiary
- A Size A
- 46.00 mm
- A1 Size A1
- 47.90 mm
- B Size B
- 32.30 mm
- C Size C
- 3.35 mm
- C1 Size C1
- 2.80 mm
- D Size D
- 24.80 mm
- E Size E
- 4.11 mm
O produkcie
BW-03-0049 - Koło kompresji
Marka: TurboCentras
TurboCentras Reference: BW-03-0049
BW-03-0049 - Alternative numbers
BWP (BorgWarner original part number): 1646 123 2001
BWP (BorgWarner original part number): 1646 123 2005
BWP (BorgWarner original part number): 5443 123 2050
BWP (BorgWarner original part number): 5443 123 2055
TCP (TurboCentras part number): BW-03-0049
TCO (TurboCentras old part number): KP38-01B
BW-03-0049 - Compatibility table
| Compressor wheel BW-03-0049 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| BorgWarner | BV38_4-1870KYE340.18AVBXC | 54389700003 | 5438 970 0003 | 55589342 |
| BorgWarner | BV38_4-1870KYE340.18AVBXC | 54389700004 | 5438 970 0004 | 55580016 |
| BorgWarner | BV38 | 54389700009 | 5438 970 0009 | 55598494 |
| BorgWarner | BV38 | 54389700010 | 5438 970 0010 | 55599546 |
| BorgWarner | BV38 | 54389700011 | 5438 970 0011 | 55486151 |
| BorgWarner | BV38 | 54389700012 | 5438 970 0012 | 55486149 |
| BorgWarner | BV38 | 54389700013 | 5438 970 0013 | 55493250 |
| BorgWarner | BV38 | 54389700014 | 5438 970 0014 | -- |
| BorgWarner | BV38 | 54389700015 | 5438 970 0015 | 55493252 |
| BorgWarner | BV38 | 54389700016 | 5438 970 0016 | 55496868 |
| BorgWarner | BV38 | 54389700021 | 5438 970 0021 | 55506594 |
| BorgWarner | BV38 | 54389700022 | 5438 970 0022 | 55506592 |
BW-03-0049 - Part Properties
Blades (Compressor wheel blades count): 6/6
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Billet
Back (Compressor wheel back design): Super
A (Size A): 46.00
A1 (Size A1): 47.90
B (Size B): 32.30
C (Size C): 3.35
C1 (Size C1): 2.80
D (Size D): 24.80
E (Size E): 4.11
54431232055, 54431232050, 16461232005, 16461232001, 1646 123 2001, 1646 123 2005, 5443 123 2050, 5443 123 2055, BW-03-0049, KP38-01B
54409880035, 54409700035, 54409880020, 54409700020, 54409880005, 54409700005, 54409700004, 54399730058, 54399720058, 54399880085, 54399700085, 54399880084, 54399700084, 54389700022, 54389700021, 54389880018, 54389700018, 54389880017, 54389700017, 54389700016, 54389700015, 54389700014, 54389700013, 54389700012, 54389700011, 54389700010, 54389700009, 54389880007, 54389700007, 54389700005, 54389700004, 54389700003, 54389880001, 54389700001, 54389700000, 144115874R, 5438 970 0000, 144117969R, 144119252R, 5438 970 0001, 5438 988 0001, 5438 970 0003, 55589342, 5438 970 0004, 55580016, 14411-0219R, 144110219R, 5438 970 0005, 144111360R, 144118607R, 5438 970 0007, 5438 988 0007, 5438 970 0009, 55598494, 5438 970 0010, 55599546, 5438 970 0011, 55486151, 5438 970 0012, 55486149, 5438 970 0013, 55493250, 5438 970 0014, 5438 970 0015, 55493252, 5438 970 0016, 55496868, 144114225R, 144114822R, 5438 970 0017, 5438 988 0017, 6260900400, 14411-0972R, 144110972R, 5438 970 0018, 5438 988 0018, 6220900500, A6220900500, 5438 970 0021, 55506594, 5438 970 0022, 55506592, 2X0253019A, 5439 970 0084, 5439 988 0084, 2X0253019B, 5439 970 0085, 5439 988 0085, 2X0253019A, 5439 972 0058, 2X0253019, 5439 973 0058, 5440 970 0004, 03L253056E, 5440 970 0005, 5440 988 0005, 03L253056Q, 5440 970 0020, 5440 988 0020, 03L253010J, 5440 970 0035, 5440 988 0035
Specyfikacja
Producent:
SKU:
BW-03-0049
Numer seryjny:
BW-03-0049
Główny numer:
KP38-01B, BW-03-0049, 1646 123 2001, 1646 123 2005, 5443 123 2050, 5443 123 2055, CW-0804B
OEM numer:
54389700003, 54389700009, 54389700011, 54389700021, 54389700013, 54389700004, 54389700010, 54389700012, 54389700014, 54389700015, 54389700016, 54389700022
