Вал турбины BW-02-0031

BW-02-0031 - Вал турбины

Бренд: TurboCentras

TurboCentras Артикул: BW-02-0031

BW-02-0031 - Альтернативные номера

BWP (BorgWarner original part number): 5439-120-5004

BWP (BorgWarner original part number): 5439-120-8501

TCP (TurboCentras part number): BW-02-0031

TCO (TurboCentras old part number): KP39-37

BW-02-0031 - Таблица совместимости

BW-02-0031 - Свойства детали

Blades (Shaft & Wheel blades count): 9

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Full

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 38.50

A1 (Size A1): 38.50

B (Size B): 34.50

C (Size C): 6.70

D (Size D): 6.00

E (Size E): 4.10

H (Size H): 15.80

L (Size L): 83.00

T (Size T): M4X0.5LH

5439-120-5004, 5439-120-8501, BW-02-0031, KP39-37

54399980127, 54399710127, 54399700127, 54399980090, 54399700090, 54399700087, 54399980080, 54399700080, 54399700076, 54399980070, 54399900070, 54399710070, 54399700070, 54399700066, 54399900054, 54399880054, 54399700054, 54399700046, 54399700030, 54399980027, 54399700027, 54399880015, 54399700015, 54399880003, 54399700003, 54399700002, 54399700001, 038253016B, 5439 970 0001, 5439 970 0002, 8200204572, 038253010K, 038253019P, 038253056C, 5439 970 0003, 5439 988 0003, 045253019A, 5439 970 0015, 5439 988 0015, 5439 970 0027, 5439 998 0027, 8200360800, 8200578315, 5439 970 0030, 8200405203, 8200507856, 8200578381, 5439 970 0046, 8200678809, 045253019J, 5439 970 0054, 5439 988 0054, 5439 990 0054, 5439 970 0066, 8200552213, 8200588232, 144116751R, 5439 970 0070, 5439 971 0070, 5439 990 0070, 5439 998 0070, 8200625683, 144114256R, 5439 970 0076, 8200808701, 5439 970 0080, 5439 998 0080, 8200846770, 5439 970 0087, 8200889697, 5439 970 0090, 5439 998 0090, 8200905276, 144115524R, 144116289R, 5439 970 0127, 5439 971 0127, 5439 998 0127

Данные обновлены: 2023-05-04 15:55:18
