Nozzle ring assy 837724-0001
Nozzle ring assy 837724-0001
- Manufacturer:
TurboCentras
- Serial number:
GA-06-0029
- Main number:
GA-06-0029, 837724-0001
- OEM number:
830324-0002, 830324-0004
About product
GA-06-0029 - Nozzle ring assy.
Brand: TurboCentras
TurboCentras Reference: GA-06-0029
GA-06-0029 - Alternative numbers
TCP (TurboCentras part number): GA-06-0029
GA-06-0029 - Compatibility table
| Nozzle ring assy. GA-06-0029 - Compatible turbochargers | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GTD1449VZK-Evo | 823665-0001 | 823665-0001, 823665-5001S | 282314A600 |
| Garrett | GTD1449VZ | 823665-0007 | 823665-0007, 823665-5007S | 282314A610 |
| Garrett | GTD1449VZ | 823665-0009 | 823665-0009, 823665-5009S | 282314A730 |
| Garrett | GTD1244VZK | 830324-0001 | 830324-0001 | -- |
| Garrett | GTD1244VZM | 830324-0002 | 830324-0002, 830324-5002S | 04L253016SV400 |
| Garrett | GTD1244VZK | 830324-0003 | 830324-0003 | 04L253016SX |
| Garrett | GTD1449VZK | 831157-0002 | 831157-0002, 831157-5002S | FB3Q-6K682-AB, FB3Q6K682AB |
| Garrett | GTD1449VZK | 831157-0003 | 831157-0003, 831157-5003S | FB3Q6K682MA, UFF01682 |
| Garrett | GTD1449VZK | 831157-0004 | 831157-0004, 831157-5004S | FB3Q6K682AC |
| Garrett | GTD1449VKZ | 831157-0005 | 831157-0005, 831157-5005S | FB3Q6K682MB |
| Garrett | GTD1449VZK | 831157-0006 | 831157-0006, 831157-5006S | FB3Q6K682AD |
| Garrett | GTD1449VKZ | 831157-0007 | 831157-0007, 831157-5007S | FB3Q6K682MC |
| Garrett | GTD1449VZK | 832642-0005 | 832642-0005, 832642-5005S | 55282310 |
| Garrett | GTD1444VZ | 838417-0001 | 838417-0001, 838417-5001S | -- |
| Garrett | GTD1444VZ | 838417-0002 | 838417-0002, 838417-5002S | GK2Q6K682BB |
| Garrett | GTD1444VZ | 838417-0003 | 838417-0003, 838417-5003S, 838417-9003S | GK2Q6K682BB |
| Garrett | GTD1444V | 838452-0001 | 838452-0001 | GK3Q6K682AA |
| Garrett | GTD1444V | 838452-0002 | 838452-0002, 838452-5002S | GK3Q6K682AB |
| Garrett | GTD1444V | 838452-0003 | 838452-0003, 838452-5003S | GK3Q6K682AC |
| Garrett | GTD1446VZ | 843259-0001 | 843259-0001 | 1044100FB040 |
| Garrett | GTD1446VZ | 843259-0003 | 843259-0003, 843259-5003S | 1044100FB040 |
| Garrett | GTD1446VZ | 846108-0002 | 846108-0002 | 1044100FD040 |
| Garrett | GTD1449VKZ | 857039-0001 | 857039-0001, 857039-5001S | 55274549 |
| Garrett | GTD1449Z | 870885-0005 | 870885-0005, 870885-5005S | C00108182 |
| Garrett | GTD1446VZ | 873597-0001 | 873597-0001, 873597-5001S | 1044100FD060 |
| Garrett | GTD1244VZ | 873732-0001 | 873732-0001, 873732-5001S | 04L253014H |
| Garrett | GTD1449VZK | 876358-0001 | 876358-0001 | C00128350 |
| Garrett | GTD1449VZK | 876358-0002 | 876358-0002 | C00128350 |
| Garrett | GTD1449Z | 876358-0003 | 876358-0003, 876358-5003S | C00185436 |
| Garrett | GTD1449VZK | 889938-0001 | 889938-0001, 889938-5001W | FB3Q6K682AB |
| Garrett | GTD1449VKZ | 889938-0003 | 889938-0003, 889938-5003W | -- |
GA-06-0029 - Part Properties
Blades (Nozzle Ring blades count): 10
A (Size A): 80.80
B (Size B): 47.65
D (Size D): 5.60
GA-06-0029
282314A600, 823665-0001, 823665-5001S, 282314A610, 823665-0007, 823665-5007S, 282314A730, 823665-0009, 823665-5009S, 830324-0001, 04L253016SV400, 830324-0002, 830324-5002S, 04L253016SX, 830324-0003, 831157-0002, 831157-5002S, FB3Q-6K682-AB, FB3Q6K682AB, 831157-0003, 831157-5003S, FB3Q6K682MA, UFF01682, 831157-0004, 831157-5004S, FB3Q6K682AC, 831157-0005, 831157-5005S, FB3Q6K682MB, 831157-0006, 831157-5006S, FB3Q6K682AD, 831157-0007, 831157-5007S, FB3Q6K682MC, 55282310, 832642-0005, 832642-5005S, 838417-0001, 838417-5001S, 838417-0002, 838417-5002S, GK2Q6K682BB, 838417-0003, 838417-5003S, 838417-9003S, GK2Q6K682BB, 838452-0001, GK3Q6K682AA, 838452-0002, 838452-5002S, GK3Q6K682AB, 838452-0003, 838452-5003S, GK3Q6K682AC, 1044100FB040, 843259-0001, 1044100FB040, 843259-0003, 843259-5003S, 1044100FD040, 846108-0002, 55274549, 857039-0001, 857039-5001S, 870885-0005, 870885-5005S, C00108182, 1044100FD060, 873597-0001, 873597-5001S, 04L253014H, 873732-0001, 873732-5001S, 876358-0001, C00128350, 876358-0002, C00128350, 876358-0003, 876358-5003S, C00185436, 889938-0001, 889938-5001W, FB3Q6K682AB, 889938-0003, 889938-5003W
