Shaft and wheel for 53039700086
Dimensions
- A Size A
- 45.00 mm
- A1 Size A1
- 45.00 mm
- B Size B
- 40.30 mm
- C Size C
- 7.70 mm
- D Size D
- 7.00 mm
- E Size E
- 4.61 mm
- H Size H
- 18.50 mm
- L Size L
- 98.00 mm
About product
Dimensions of the Shaft and wheel:
Blades (Shaft & Wheel blades count): 11
Rotation (Shaft & Wheel rotation direction): Standard
Type (Shaft & Wheel type): Straight
Back (Shaft & Wheel back type): Full
P.R. (Shaft & Wheel piston rings count): Single
A (Size A): 45.00
A1 (Size A1): 45.00
B (Size B): 40.30
C (Size C): 7.70
D (Size D): 7.00
E (Size E): 4.61
H (Size H): 18.50
L (Size L): 98.00
T (Size T): M4.5X0.5LH
Shaft and wheel fits to the next turbochargers:
- 53039700086 53039880086 53039700087 53039700105 53039880105 53039900105 53039700106 53039880106 53039900106 53039700112 53039880112 53039700117 53039700118 53039700119 53039700123 53039700134 53039880134 53039700136 53039880136 53039700141 53039880141 53039700146 53039880146 53039700159 53039700160 53039880160 53039700161 53039700163 53039880163 53039900163 53039700165 53039700180 53039700181 53039700215 53039700292 53039700298 53039700307 53039700426 53039880426 53039700427 53039700440 53039700449
-
06F145701B 06F145701C 06F145701F 06D145701B 06D145701C 06D145701F 06F145701D 06F145701E 06F145701G 06F145701H 06D145701D 06D145701E 06D145701G 06D145701H 06D145701J 06J145701B 06J145701H 0375N8 756542301 V755569880-04 V756542380-01 1165756542401 1165756542402 756542401 756542402 V755569780-04 06H145701E 06H145701G 06H145701K 06J145701J 06J145701L 06J145702C 06J145701P 06J145701R 06H145701F 06H145701L 11657575653 11657583149 7575653 7575659-01 7575659-02 7583149 06J145702G 06J145702F 11657595351 11657595678 11657647003 7595351 7595678 7647003 06H145701M V760088280-01 11657600881 11657647002 7600881 7647002 28231-2B700 28500-2B700 9803546480 11657649495 11657649496 7649495 7649496 28231-2B710 28500-2B710 9809028880 28231-2B730 28500-2B730 111B100-XEC06 10945468-00
Specifications
Manufacturer:
SKU:
BW-02-0042
Serial number:
BW-02-0042
Main number:
K03-41, 5303 120 5036, BW-02-0042
OEM number:
5303-120-5036, 53039700123, 53039700112, 53039700117, 53039700118, 53039700119, 53039700134, 53039700136, 53039700141, 53039700159, 53039700160, 53039700161, 53039700163, 53039700165, 53039700180, 53039700181, 53039700292, 53039700426, 53039700105, 53039700106, 53039700146, 53039700298
