Вал турбины для 9VA15

Размеры Валa турбины:

IH-02-0037 - Compatibility table

Shaft and wheel IH-02-0037 - Compatible turbochargers

TURBO MAKER	TURBO MODEL	TURBO REFERENCE	TURBO PART NUMBER	TURBO OE NUMBER
IHI	JHJ	06H145701P	--	06H145701P
IHI	JHJ	06H145701Q	--	06H145701Q
IHI	JHJ	06H145703N	--	06H145703N
IHI	JHJ	06H145703P	--	06H145703P
IHI	JHJ	06H145703Q	--	06H145703Q
IHI	JHJ	06H145703R	--	06H145703R
IHI	JHJ	06H145703S	--	06H145703S
IHI	JHJ-RHF5	06H145704M	--	06H145704M
IHI	JHJ	9VA03	9VA03, F51CAF-SR015B	--
IHI	JHJ	9VA14	9VA14	--
IHI	JH5-RHF5	9VA15	9VA15, F51CAY-SR038B	06J145702Q, 06J145702S, 06J145703T, 06J145713A, 06J145713F, 06J145722A

IH-02-0037 - Part Properties

Blades (Shaft & Wheel blades count): 7

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Open

P.R. (Shaft & Wheel piston rings count): Single

A (Size A): 52.10

A1 (Size A1): 42.50

B (Size B): 44.00

C (Size C): 6.76

D (Size D): 8.00

E (Size E): 5.10

H (Size H): 21.00

L (Size L): 102.00

T (Size T): M5.0X0.5-LH

---

IH-02-0037, RHF5-44

---

06H145701P, 06H145701Q, 06H145703N, 06H145703P, 06H145703Q, 06H145703R, 06H145703S, 06H145704M, 9VA03, F51CAF-SR015B, 9VA14, 06J145702Q, 06J145702S, 06J145703T, 06J145713A, 06J145713F, 06J145722A, 9VA15, F51CAY-SR038B

---
