Вал турбины для 49377-02700

Размеры Валa турбины:

Blades (Shaft & Wheel blades count): 9

Rotation (Shaft & Wheel rotation direction): Standard

Type (Shaft & Wheel type): Straight

Back (Shaft & Wheel back type): Full

P.R. (Shaft & Wheel piston rings count): Twin

A (Size A): 43.00

A1 (Size A1): 43.00

B (Size B): 39.45

C (Size C): 9.05

D (Size D): 7.88

E (Size E): 5.08

F (Size F): 51.00

G (Size G): 33.40

H (Size H): 23.00

L (Size L): 92.50

T (Size T): M5.0X0.8LH

Вал турбины подходит для следующих номеров турбин:

• 49377-02700 49377-02710 49377-02720 49377-02730 49377-02740 49377-02760 49377-02770 49377-02780 49377-02790 49377-02800 730640-0001 730640-5001S 750952-0001 750952-5001S 750952-0004 750952-5004S 750952-0007 750952-5007S 750952-0010 750952-5010S 750952-0013 750952-5013S 750952-0014 750952-5014S 750952-0017 750952-5017S 759688-0002 759688-5002S 759688-0003 759688-0005 759688-0007 759688-0009 759688-5009S 760699-0002 760699-5002S 760699-0003 760699-5003S 760699-0004 760699-5004S 760699-9004W 760699-0006 760699-5006S 760700-0002 760700-0003 760700-5003S 760700-0004 760700-5004S 760700-9004S 760700-0005 762965-0001 762965-5001S 762965-0002 762965-5002S 762965-0003 762965-5003S 762965-0007 762965-5007S 762965-0008 762965-5008S 762965-0009 762965-5009S 762965-0010 762965-0017 762965-5017S 762965-0018 762965-0020 762965-5020S 762965-9020S 763091-0001 763091-0004 763091-5004S 765176-0001 765176-5001S 765176-0002 765176-0003 775159-0001 778400-0001 778400-0002 778400-0003 778400-5003S 778400-0004 778400-5004S 778400-0005 778400-5005S 778400-9005S 780502-0001 780502-5001S 780502-0003 782097-0001 782097-5001S 782097-9001W 783887-0001 798015-0002 798015-5002S 802250-0003 802250-5003S 802250-0004 802250-5004S 806493-0002 806493-5002S 806850-0001 806850-5001S 806850-0003 806850-5003S 806850-0005 806850-5005S 806850-5005W 806850-9005W 808031-0001 808031-5001S 808031 0005 808031-5005S 808031-0006 808031-5006S 808549-0001 808549-5001S 808549-0002 808549-0003 808549-5003S 808549-0004 808549-5004S
• N1118.3DZ-040G 11.3Z-18020-A01 11.3Z-18020-B01 11.3Z-18020-C01 YN30QNE-8200-SS YN30QNE-8200-SS-1 YN30QNE-8200-FS YN30QNE-8200-FS-1 YN30QNE-08200-SSA 28200-4A200 282004A200 77980551 77980551 77980551 77980551 77980551 77980551 A6460900480 070145701N 070145701NV204 070145701N 070145701NV210 070145701N 070145701Q 070145701QV210 070145701Q 070145701QV210 11657794022 7794020G 11657794022 7794020G 7794022G 11657794022 7794020H07 11657794022 7794021H07 7794022H07 7794021K10 7794020F 8200611413A 8200769142 02C2C40364 AX2Q6K682CA LR013202 AX2Q6K682CB C2Z19947 JDE36219 AX2Q6K682CB 28231-2F100 282312F100 8200870469 6710900380 A6710900380 5801379078 5802040843 14411 LC30B 5801415508 5801894377 5801415508 5801894377 5801415508 5801894377 28231-2F750 504388383 504388383 504388383
