Уплотнительное кольцо (вала) H1C-170 к 3522778
Уплотнительное кольцо (вала) H1C-170 к 3522778
- Производитель:
TurboCentras
- Серийный номер:
H1C-170
- Основной номер:
H1C-170, PR-37-0009
- OEM-номер:
8363-39028 3802319 3802594 420597, 5003086, 503524560 3802298 8107467 4824256 4881600, 4881613, 8363-39401 3802310, CBU 1862 3802300 3802301 51.09100-7232 51.09100-7241, 51.09100-7255, 65.09100-7241 -- 3802146, 3802302 064.1852.4 3802348 8114137
О товаре
H1C-170 - Уплотнительное кольцо (вала)
Бренд: TurboCentras
TurboCentras Артикул: H1C-170
H1C-170 - Альтернативные номера
TCO (TurboCentras old part number): H1C-170
H1C-170 - Таблица совместимости
Piston ring H1C-170 - Совместимые турбокомпрессоры | ||||
---|---|---|---|---|
ПРОИЗВОДИТЕЛЬ ТУРБИНЫ | МОДЕЛЬ ТУРБИНЫ | АРТИКУЛ ТУРБИНЫ | НОМЕР ТУРБИНЫ | OE НОМЕР ТУРБИНЫ |
Holset | H1C | 3520734 | 3520734 | -- |
Holset | H1C | 3522068 | 3522068, 3522069, 3522069H | 3802317 |
Holset | H1C | 3522778 | 166592, 3522777, 3522777H, 3522777HX, 3522778, 466563-0003 | 3802289, J907026, J907028, J907029, J919113, J919115, J919117, J919121 |
Holset | H1C | 3522900 | 3520030, 3520030H, 3520030HX, 3522900 | 3802290 |
Holset | H2A | 3523295 | 3523295, 3523296, 4033533H | 420521 |
Holset | H1C | 3523518 | 3523518, 3523519, 3523519H | 3802293 |
Holset | H2A | 3523649 | 3523649, 3591624, 3591625, 3591626, 4033070H | 4835338, 8107135, 8107560 |
Holset | H2A | 3523885 | 3523885, 3523886 | -- |
Holset | H2A | 3523982 | 3523982 | -- |
Holset | H1E | 3524100 | 3524100, 3524101, 3524101H | -- |
Holset | H1E | 3524128 | 3524128, 3524129, 3524129H | 8363-39028 |
Holset | H1C | 3524311 | 3524311, 3524312, 3524312H | 3802319 |
Holset | H1C | 3524424 | 3524424, 3524427, 3524427H | 3802594 |
Holset | H2A | 3524559 | 3524559, 3524560, 4033402H | 420597, 5003086, 503524560 |
Holset | H1C | 3525103 | 3521366, 3521366H, 3525103 | 3802298 |
Holset | H2A | 3525186 | 3525186, 3525187 | 8107467 |
Holset | H2A | 3525420 | 3525420, 3525421, 4033278H, 5327 988 7010 | 4824256 |
Holset | H1E | 3525471 | 3525471, 3525472, 4033233H, 466742-0003, 466742-0005 | 4881600, 4881613, 8363-39401 |
Holset | H1C | 3525648 | 3520055, 3520055H, 3525648 | 3802310, CBU 1862 |
Holset | H1C | 3525669 | 3525669, 3525670, 3525670H | 3802300 |
Holset | H1C | 3525720 | 3525720, 3525721, 3525721H | 3802301 |
Holset | H1E | 3526025 | 3525424, 3526025, 3526025, 4033217H | 51.09100-7232 |
Holset | H1E | 3526575 | 3526575, 3526576, 4033599H | 51.09100-7241, 51.09100-7255, 65.09100-7241 |
Holset | H1E | 3526590 | 3526590 | -- |
Holset | H1C | 3526739 | 3526739, 3526740, 3526740H, 466565-0003 | 3802146, 3802302 |
Holset | H1C | 3527396 | 3527396, 3527397, 3786891, 3786891H | 064.1852.4 |
Holset | H1C | 3528237 | 3528237, 3528238, 3528238H | 3802348 |
Holset | H1E | 3528352 | 3528352, 3528353, 4033098H | 8114137 |
Holset | H1C | 3528739 | 3528739, 3528740 | -- |
Holset | H1C | 3528741 | 3528741 | -- |
Holset | H1C | 3528743 | 3528743 | -- |
Holset | H1C | 3528745 | 3528745, 3528746, 3535428 | -- |
Holset | H1C | 3528747 | 3528747 | -- |
Holset | H1C | 3528749 | 3528749, 3528750 | J908294, J918248, J919163 |
Holset | H1C | 3528759 | 3528759, 3528760 | -- |
Holset | H1C | 3528761 | 3528761, 3528762, 3535434, 3535435 | -- |
Holset | H1C | 3528763 | 3528763, 3528764, 3535436, 3535437, 3535438 | -- |
Holset | H1C | 3528767 | 3528767, 3528768, 3535439, 3535440, 3535441 | -- |
Holset | H1C | 3528771 | 3528771, 3528772 | -- |
Holset | H1C | 3528773 | 3528773, 3528774, 3530715, 3534027, 3536028, 3536678, 3536679, 3536680 | -- |
Holset | H1C | 3528894 | 3528894, 3528895 | -- |
Holset | H1C | 3528918 | 3528918, 3528919, 3535443, 3535444, 3535445, 3535446 | -- |
Holset | H1C | 3528920 | 3528920, 3528921 | -- |
Holset | H1C | 3529008 | 3529008, 3529009, 3535447, 3535448 | -- |
Holset | H1E | 3529154 | 3529154 | -- |
Holset | H1C | 3529171 | 3528580, 3529171, 4033588, 4033588H | 2674A029 |
Holset | WH1E | 3529620 | 3529620, 3530094 | 51.09100-7298 |
Holset | H1C | 3530288 | 3530288, 3530289 | 127-0402 |
Holset | H1C | 3530734 | 3530734, 3530740 | -- |
Holset | H1C | 3530879 | 3530879, 3530883, 4033906H | 865065 |
Holset | H1C | 3531152 | 3531152, 3531153, 4033531, 4033531H | 0145-0640, 0145-0748 |
Holset | H1E | 3531198 | 3531198, 3531199, 4033137H | 8009066 |
Holset | H1C | 3531697 | 3531697, 3531811 | 3802392 |
Holset | H1C | 3532201 | 3531028, 3532201 | -- |
Holset | H1C | 3532205 | 3531032, 3531032H, 3532205 | -- |
Holset | H1C | 3532207 | 3531034, 3531034H, 3532207 | 3802297 |
Holset | H1C | 3532210 | 3531038, 3531038H, 3532210 | 3802233 |
Holset | H1C | 3532211 | 3531040, 3531040H, 3532211, 466575-0002 | 3802235, 466575-0002 |
Holset | H1C | 3532793 | 3532793, 3532830 | 0145-0682 |
Holset | WH1C | 3533121 | 3533121, 3533122 | -- |
Holset | H1C | 3533518 | 3533518, 3533521, 3536682 | -- |
Holset | WH1C | 3533563 | 3533563, 3533564, 3534369, 3534370, 3536045, 3536046 | 3533564, 3534369, 3534370, 3536045, 3536046 |
Holset | H1C | 3533732 | 3533732, 3533733, 3533734 | -- |
Holset | H1E | 3533915 | 3533915, 3537689, 3537690, 3537691, 3537692, 3537693, 3537694, 3537695 | 51.09100-7278, 51.09100-7299, 51.09100-7324, 51.09100-7341, 51.09100-7342, 51.09100-7344, 51.09100-7345, 51.09100-7387 |
Holset | WH1C | 3534023 | 3534023, 3534024 | 3802583 |
Holset | WH1C | 3534241 | 3534241, 3534242, 3534242H | 3802586 |
Holset | H1C | 3534285 | 3534285, 3534286, 3592224, 3592225, 3592226 | 3800990 |
Holset | H1C | 3534371 | 3534371, 3534372, 3534372H | 3802588 |
Holset | H1E | 3534494 | 3534494, 3534495, 4033618H | 866779 |
Holset | WH1E | 3534617 | 3534408, 3534615, 3534616, 3534617, 3534619, 4033891H | 477835, 477866, 477867, 477869 |
Holset | H1C | 3534995 | 3534995, 3534996 | 3802617 |
Holset | WH1E | 3535103 | 3535103, 3535104 | 51.09100-7311 |
Holset | WH1C | 3535666 | 3535666, 3535667 | -- |
Holset | WH1E | 3535970 | 3535970, 3535972, 4033895H | 477869 |
Holset | WH1C | 3536050 | 3536050, 3536051 | 3802891 |
Holset | H1E | 3537302 | 3537302, 3537667 | 51.09100-7393 |
Holset | WH1E | 3537303 | 3537303 | -- |
Holset | H1C | 3537355 | 3537355, 3537356, 4033017H | 8019362 |
Holset | WH1E | 3537408 | 3537408, 3537545, 3537546 | 51.09100.7369, 51.09100.7375 |
Holset | WH1E | 3538031 | 3538031 | -- |
Holset | H2A | 3538385 | 3538385, 3538386 | 3538386 |
Holset | H1C | 3538723 | 3538723, 3538760 | 3802870 |
Holset | H1C | 3538780 | 3538780, 3538781 | 3802911 |
Holset | WH1C | 3539428 | 3539428, 3539429, 3539956 | A3960408, A3960454 |
Holset | H1C | 3539466 | 3539466, 3539467, 3539467H | -- |
Holset | H1C | 3539472 | 3539472, 3539473, 3539473H | -- |
Holset | H1E | 3580178 | 3580178, 4032978, 4032978H, 466214-0014, 466214-0015, 466214-0016, 466214-0017, 466214-0018, 466214-0019, 466214-0022, 466214-0023, 466214-0028, 466214-0029, 466214-0030, 466214-0031, 466214-0035, 466214-0036, 466214-0038, 466214-0039, 5327 988 6424, 5327 988 6425, 5327 988 6502, 5327 988 6507, 5327 988 6606 | 0030960099KZ, 0030960199KZ, 0030960899KZ, 0030960999KZ, 0030962099KZ, 0030962199KZ, 0030967699KZ, 0030967799KZ, 0030968999KZ, 0040960799KZ, 0040960899KZ, 0040960999KZ, 0040961099KZ, 0040961899KZ, 0040961999KZ, 0040962099KZ, 0040962199KZ, 0040962899KZ, 0040962999KZ, 0040965299KZ, 0040965399KZ, 0040965499KZ, 0040965599KZ, 0040968599KZ, 313163, 40966399, 50962699, 50969399 |
Holset | H1E | 3580253 | 3580253 | -- |
Holset | H1E | 3580266 | 169146, 194636, 197354, 310769, 313050, 3580266, 4033167, 4033167H, 465366-0001, 465366-0003, 465366-0004, 465366-0005, 465366-0010, 465366-0013, 465366-0017, 465366-0018, 465366-0019, 465366-0020, 465366-0021, 465366-0022, 465366-0023, 465366-0024, 5327 988 6070, 5327 988 6072, 5327 988 6440, 5327 988 6441 | 3520964299KZ, 3520964399KZ, 3520964899KZ, 3520964999KZ, 3520965099KZ, 3520965199KZ, 3520965299KZ, 3520965399KZ, 3520966899KZ, 3520968299KZ, 3520968399KZ, 3520968499KZ, 3520968599KZ, 3660960299KZ, 3660960699KZ, 3660960799KZ, 3660960899KZ, 3660960999KZ, 3660961099KZ, 3660961399KZ, 3660961499KZ, 3660961599KZ, 3660961699KZ, 3660962299KZ, 3660962699KZ, 3660962899KZ, 3660963699KZ, 3660963899, 3660963899KZ, 3760960099KZ, 3760960399KZ, 3760960699KZ |
Holset | H1E | 3580274 | 313394, 313425, 315101, 3580274, 3580274H, 466646-0013, 466646-0017, 466646-0018, 466646-0019, 466646-0020, 466646-0024, 466646-0025, 466646-0026, 5327 988 6444, 5327 988 6710 | 3660962999KZ, 3660963499KZ, 3660964099KZ, 3660964199KZ, 3660964299KZ, 3660964499KZ, 3660965199KZ, 3660965299KZ, 3660965399KZ, 3660965499KZ, 3660965599KZ, 3660965699KZ, 3660965799KZ, 3660965899KZ, 366966199KZ, 366966299KZ, 366968699KZ |
Holset | H1E | 3580770 | 3580770, 3580770H, 466780-0001, 466780-0004 | 284555, 90617 |
Holset | WH1E | 3590501 | 3590501, 3590537 | 51.09100.7369 |
Holset | WH1E | 3593349 | 3593349, 3593359 | AKZ-1118010 |
Holset | HX35W | 3594634 | 3594634, 3594635, 3594635H | 4955743 |
Holset | HX35W | 3595159 | 3595159 | -- |
Holset | HX35W | 3595933 | 3595275, 3595933 | -- |
Holset | HX35 | 3596952 | 3596952, 3596953, 3596953H | -- |
Holset | HX35 | 3597248 | 3597248, 3597249, 3597249H | 4025396 |
Holset | HX35G | 3597411 | 3597411, 3597412, 3597413 | 4025410 |
Holset | HX35G | 3597414 | 3597414, 3597415 | 4025411 |
Holset | HX35G | 3597416 | 3597416, 3597417 | 4025412 |
Holset | HX35G | 3597422 | 3597422, 3597423, 3597424, 3597425 | 4025414 |
Holset | HX35W | 3597508 | 3597508, 3597509, 3597509H | -- |
Holset | HX35 | 3599034 | 3597068, 3599034 | -- |
Holset | HX35G | 3599491 | 3599491, 4039953, 4039954 | 4955457 |
Holset | HX35G | 3768610 | 3768610, 3768611, 3771572 | -- |
Holset | HX35W | 3770570 | 3770568, 3770568H, 3770570 | 2882069 |
Holset | HE300WG | 3770571 | 2882068H, 3770569, 3770571 | 2882068 |
Holset | HX35W | 3776341 | 3776341, 3776342, 3776343, 3786698H | -- |
Holset | H1C | 3779713 | 3528744, 3530721, 3535422, 3535423, 3535424, 3535425, 3535426, 3535427, 3536677, 3539310, 3779713 | -- |
Holset | HE351W | 3788093 | 3787199, 3787199H, 3788093, 3788094, 3788095, 3788096, 3788098 | -- |
Holset | HE351W | 3790648 | 3788097, 3790648 | -- |
Holset | H1E | 4027683 | 4027683, 4033712H, 466588-0001, 466588-0002 | 471740, 471897 |
Holset | H1E | 4027762 | 4027762, 4033190H, 466214-0024, 466214-0025, 466214-0026, 466214-0027, 466214-0032, 466214-0033, 466214-0034 | 004 096 4099, 004 096 4199, 004 096 4299, 004 096 4399, 004 096 5699, 004 096 5799, 004 096 7699 |
Holset | H1E | 4027855 | 4027855 | -- |
Holset | HX35 | 4035228 | 3787037H, 4035228, 4035229, 4035230, 4035231 | 403-1118010, A3919153 |
Holset | HX40W | 4035263 | 4035263, 4035264, 4035265 | 1118010/BKZ-050, 1118010H/BKZ |
Holset | HX35 | 4049346 | 3787142H, 4049340, 4049341, 4049346 | 403-1118010, 403-1118010(A) |
Holset | HX35W | 4050267 | 3787141H, 4050267, 4050268 | 2881915 |
H1C-170
