Крыльчатка компрессора 452005-0001

GA-03-0119 - Крыльчатка компрессора

Бренд: TurboCentras

TurboCentras Артикул: GA-03-0119

GA-03-0119 - Альтернативные номера

GHP (Garrett original part number): 410450-0003

GHP (Garrett original part number): 410450-0008

GHP (Garrett original part number): 410450-0011

TCP (TurboCentras part number): GA-03-0119

TCO (TurboCentras old part number): T2-02

GA-03-0119 - Таблица совместимости

Крыльчатка компрессора GA-03-0119 - Совместимые турбокомпрессоры
ПРОИЗВОДИТЕЛЬ ТУРБИНЫ	МОДЕЛЬ ТУРБИНЫ	АРТИКУЛ ТУРБИНЫ	TURBO PART NUMBER	OE НОМЕР ТУРБИНЫ
Garrett	TB0246	452005-0001	452005-0001	--
Garrett	TB0249	452005-0002	452005-0002	ETC6878
Garrett	TB0267	454052-0001	454052-0001	77521310
Garrett	TB0267	454052-0002	454052-0002	77521310
Garrett	TB0269	454055-0001	454055-0001	77403100
Garrett	TB0269	454055-0002	454055-0002	1307679080
Garrett	TB0270	454067-0001	454067-0001	7700862161
Garrett	TB0270	454067-0002	454067-0002	7.700.862.161
Garrett	TB0293	454112-0002	454112-0002	--
Garrett	TB0293	454112-0003	454112-0003	7700868124, 8111321, 8602092, M855994
Garrett	TB0293	454112-0004	454112-0004	7700868124, 8111321, 8602092
Garrett	TB0293	454112-0005	454112-0005	7.700.108.864
Garrett	TB02	454204-0001	454204-0001	--
Garrett	TB02	454204-0002	454204-0002	--
Garrett	TB02	454225-0001	454225-0001	--
Garrett	TB02	454225-0002	454225-0002	--
Garrett	TB0238	465165-0001	465165-0001	XV884B6K682BA
Garrett	TB0250	465187-0001	465187-0001	V90FB6K682BA
Garrett	TB0250	465187-0002	465187-0002	--
Garrett	TB023	465265-0001	465265-0001	--
Garrett	TB0234	465343-0001	465343-0001	9301152480
Garrett	TB0234	465343-0002	465343-0002	9613719880
Garrett	TB0235	465367-0001	465367-0001	6001021213/4
Garrett	TB0235	465367-0002	465367-0002	6001021213/4
Garrett	TB0235	465367-0003	465367-0003	--
Garrett	TB0256	465505-0001	465505-0001	7.700.853.974
Garrett	TB0256	465505-0002	465505-0002	7.700.872.215
Garrett	TB0256	465505-0003	465505-0003	--
Garrett	TB0245	465557-0001	465557-0001	76577310
Garrett	TB0236	465699-0001	465699-0001	--
Garrett	TB0258	466181-0001	466181-0001	--
Garrett	TB0203	466196-0001	466196-0001	6.001.007.443
Garrett	TB0203	466196-0002	466196-0002	6001003037, 7.701.464.106
Garrett	TB0203	466196-0003	466196-0003	6.001.008.162
Garrett	TB0203	466196-0004	466196-0004	6.001.008.165
Garrett	TB0203	466196-0005	466196-0005	6.001.009.233
Garrett	TB0203	466196-0006	466196-0006	--
Garrett	TB0208	466250-0002	466250-0002	--
Garrett	TB0212	466416-0003	466416-0003	--
Garrett	TB0212	466416-0004	466416-0004	14411-35M60
Garrett	TB0212	466416-0006	466416-0006	--
Garrett	TB0212	466416-0007	466416-0007	--
Garrett	TB0213	466450-0001	466450-0001	--
Garrett	TB0216	466452-0001	466452-0001	JR775043
Garrett	TB0216	466452-0002	466452-0002	7700727641
Garrett	TB0214	466506-0001	466506-0001	6.001.006.841
Garrett	TB0214	466506-0002	466506-0002	6.001.007.473
Garrett	TB0214	466506-0003	466506-0003	6.001.008.163
Garrett	TB0214	466506-0004	466506-0004	6.001.008.164
Garrett	TB0214	466506-0005	466506-0005	6.001.009.280
Garrett	TB0214	466506-0006	466506-0006	6.001.009.281
Garrett	TB0214	466506-0007	466506-0007	--
Garrett	TB0214	466506-0008	466506-0008	--
Garrett	TB0214	466506-0009	466506-0009	--
Garrett	TB0231	466686-0001	466686-0001	--
Garrett	TB0221	466694-0002	466694-0002	--
Garrett	TB0225	466728-0001	466728-0001	75970610
Garrett	TB0226	466842-0001	466842-0001	--
Garrett	TB0226	466842-0002	466842-0002	ETC6878
Garrett	TB1901	466941-0001	466941-0001	14411-5C900
Garrett	TB1901	466941-0002	466941-0002	14411-5C902
Garrett	TB1902	466943-0001	466943-0001	14411-3C600
Garrett	T2	704667-0002	704667-0002	--

GA-03-0119 - Свойства детали

Blades (Compressor wheel blades count): 6/6

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Cast

Back (Compressor wheel back design): Super

A (Size A): 48.00

A1 (Size A1): 48.00

B (Size B): 34.00

C (Size C): 4.75

C1 (Size C1): 2.40

D (Size D): 24.50

E (Size E): 6.00

---
