Kompressionsrad 723340-0011
Abmessungen
- A Size A
- 44.00 mm
- A1 Size A1
- 44.00 mm
- B Size B
- 31.10 mm
- C Size C
- 3.30 mm
- C1 Size C1
- 2.40 mm
- D Size D
- 22.60 mm
- E Size E
- 5.08 mm
Über das Produkt
GA-03-0052 – Kompressionsrad
Marka: TurboCentras
TurboCentras Reference: GA-03-0052
GA-03-0052 - Alternative numbers
GHP (Garrett original part number): 704771-0002
GHP (Garrett original part number): 704771-0009
TCP (TurboCentras-Teilenummer): GA-03-0052
TCO (TurboCentras old part number): GT15-24
GA-03-0052 – Kompatibilitätstabelle
| Kompressorrad GA-03-0052 – Kompatible Turbolader | ||||
|---|---|---|---|---|
| TURBO MAKER | TURBO MODEL | TURBO REFERENCE | TURBO PART NUMBER | TURBO OE NUMBER |
| Garrett | GT1544V | 723340-0011 | 723340-0011 | -- |
| Garrett | GTA1544VK | 723340-0012 | 723340-0012, 723340-5012S | 4U3Q6K682BJ |
| Garrett | GTA1544VK | 723340-0013 | 723340-0013, 723340-5013S, 723340-9013S | 0375K4, 4U3Q6K682BK |
| Garrett | GT1544VK | 723341-0011 | 723341-0011 | 4U3Q6K682AJ |
| Garrett | GTA1544VK | 723341-0012 | 723341-0012 | 4U3Q6K682AJ |
| Garrett | GTA1544VK | 723341-0013 | 723341-0013, 723341-5013S, 723341-9013S | 0375K3, 4U3Q6K682AK |
| Garrett | GTA1544VK | 726422-0012 | 726422-0012, 726422-5012S | 02XR851772, 4R8Q6K682BK, XR853070E |
| Garrett | GTA1544VK | 726422-0013 | 726422-0013, 726422-5013S | 02XR853070, 4R8Q6K682BL, XR853070E |
| Garrett | GTA1544VK | 726423-0012 | 726423-0012, 726423-5012S | 02XR851771, 4R8Q6K682AK, XR853070E |
| Garrett | GTA1544VK | 726423-0013 | 726423-0013, 726423-5013S | 02XR863069, 4R8Q6K682AL, XR853070E |
| Garrett | GT1544V | 740611-0001 | 740611-0001, 740611-5001S | 28201-2A100, 282012A100 |
| Garrett | GT1544V | 740611-0002 | 740611-0002, 740611-5002S, 740611-5002W, 740611-9002W | 28201-2A400, 282012A400 |
| Garrett | GT1544V | 740611-0003 | 740611-0003, 740611-5003S | 282012A110 |
| Garrett | GT1544V | 740611-0005 | 740611-0005, 740611-5005S | 282112A510A |
| Garrett | GT1444V | 751418-0002 | 751418-0002, 751418-5002S | 172010N010 |
| Garrett | GT1544V | 752341-0003 | 752341-0003 | 02C2C28847, 6R8Q6K682BA |
| Garrett | GTA1544VK | 752341-0006 | 752341-0006 | 02C2C35175, 6R8Q6K682AD, 6R8Q6K682BB, 6R8Q6K682BD |
| Garrett | GTA1544VK | 752343-0003 | 752343-0003, 752343-5003S | 02C2C28846, 6R8Q6K682AA, C2C35176E, XR853070E |
| Garrett | GTA1544VK | 752343-0006 | 752343-0006, 752343-5006S, 752343-9006S | 02C2C35176, 6R8Q6K682AD, C2C35176E, XR853070E |
| Garrett | GTA1444V | 755925-0001 | 755925-0001, 755925-5001S | 11657799433, 172010N020 |
| Garrett | GT1444V | 758870-0001 | 758870-0001, 758870-5001S | 172010N010, 172010N010C |
| Garrett | GT1544V | 766111-0001 | 766111-0001, 766111-5001S, 766111-9001S | 282012A610 |
| Garrett | GT1444V | 766259-0001 | 766259-0001, 766259-5001S | 172010N030, 172010N030B |
| Garrett | GT1544V | 782403-0001 | 782403-0001, 782403-5001S | 28201A100 |
| Garrett | GT1544V | 782403-0002 | 782403-0002 | 28201A120 |
| Garrett | GT1544V | 782403-0003 | 782403-0003 | -- |
| Garrett | GT1544V | 782403-0005 | 782403-0005 | -- |
| Garrett | GT1544V | 782404-0001 | 782404-0001, 782404-5001S | 282012A410 |
GA-03-0052 – Teileigenschaften
Schaufeln (Anzahl der Schaufeln am Verdichterrad): 6/6
Drehrichtung (Drehrichtung des Verdichterrads): Standard
Typ (Fertigungsart des Verdichterrads): Guss
Rückseite (Ausführung der Rückseite des Verdichterrads): Super
A (Größe A): 44,00
A1 (Größe A1): 44,00
B (Größe B): 31,10
C (Größe C): 3,30
C1 (Größe C1): 2,40
D (Größe D): 22,60
E (Größe E): 5,08
704771-0002, 704771-0009, GA-03-0052, GT15-24
723340-0011, 4U3Q6K682BJ, 723340-0012, 723340-5012S, 0375K4, 4U3Q6K682BK, 723340-0013, 723340-5013S, 723340-9013S, 4U3Q6K682AJ, 723341-0011, 4U3Q6K682AJ, 723341-0012, 0375K3, 4U3Q6K682AK, 723341-0013, 723341-5013S, 723341-9013S, 02XR851772, 4R8Q6K682BK, 726422-0012, 726422-5012S, XR853070E, 02XR853070, 4R8Q6K682BL, 726422-0013, 726422-5013S, XR853070E, 02XR851771, 4R8Q6K682AK, 726423-0012, 726423-5012S, XR853070E, 02XR863069, 4R8Q6K682AL, 726423-0013, 726423-5013S, XR853070E, 28201-2A100, 282012A100, 740611-0001, 740611-5001S, 28201-2A400, 282012A400, 740611-0002, 740611-5002S, 740611-5002W, 740611-9002W, 282012A110, 740611-0003, 740611-5003S, 282112A510A, 740611-0005, 740611-5005S, 172010N010, 751418-0002, 751418-5002S, 02C2C28847, 6R8Q6K682BA, 752341-0003, 02C2C35175, 6R8Q6K682AD, 6R8Q6K682BB, 6R8Q6K682BD, 752341-0006, 02C2C28846, 6R8Q6K682AA, 752343-0003, 752343-5003S, C2C35176E, XR853070E, 02C2C35176, 6R8Q6K682AD, 752343-0006, 752343-5006S, 752343-9006S, C2C35176E, XR853070E, 11657799433, 172010N020, 755925-0001, 755925-5001S, 172010N010, 172010N010C, 758870-0001, 758870-5001S, 282012A610, 766111-0001, 766111-5001S, 766111-9001S, 172010N030, 172010N030B, 766259-0001, 766259-5001S, 28201A100, 782403-0001, 782403-5001S, 28201A120, 782403-0002, 782403-0003, 782403-0005, 282012A410, 782404-0001, 782404-5001S
Spezifikation
Hersteller:
SKU:
GA-03-0052
Seriennummer:
GA-03-0052
Hauptnummer:
GT15-24, GA-03-0052, 704771-0002, 704771-0009, CW-0194
OEM-Nummer:
723341-0012, 723341-0013, 740611-0001, 740611-0002, 740611-0003, 740611-0005, 751418-0002, 752341-0003, 752341-0006, 752343-0006, 766111-0001, 782403-0001, 782404-0001, 723340-0012, 726422-0012, 726423-0013, 758870-0001, 766259-0001, 723340-0011, 723340-0013, 723341-0011, 726422-0013, 726423-0012, 752343-0003, 755925-0001, 782403-0002, 782403-0003, 782403-0005
